100mm Airway Laryngoscope 250V 50 Hz Video Intubation Devices
100mm Airway Laryngoscope 250V 50 Hz Video Intubation Devices
100mm Airway Laryngoscope 250V 50 Hz Video Intubation Devices
100mm Airway Laryngoscope 250V 50 Hz Video Intubation Devices
100mm Airway Laryngoscope 250V 50 Hz Video Intubation Devices
100mm Airway Laryngoscope 250V 50 Hz Video Intubation Devices
100mm Airway Laryngoscope 250V 50 Hz Video Intubation Devices
100mm Airway Laryngoscope 250V 50 Hz Video Intubation Devices
100mm Airway Laryngoscope 250V 50 Hz Video Intubation Devices
100mm Airway Laryngoscope 250V 50 Hz Video Intubation Devices
100mm Airway Laryngoscope 250V 50 Hz Video Intubation Devices
100mm Airway Laryngoscope 250V 50 Hz Video Intubation Devices
Specifications
Brand Name :
HAIYE
Model Number :
HYHJ-KC
Certification :
CE ,ISO13485 ,FDA
Place of Origin :
China
MOQ :
1 set
Price :
USD1000-USD1500/Set
Payment Terms :
L/C, D/P, T/T
Supply Ability :
1000 sets
Delivery Time :
5-8days
Packaging Details :
Carton
Product name :
Video Laryngoscope
Screen :
3.0 inch
Resolution :
960*480
Pixel :
2 Million
Blade Material :
Stainless steel
Certificate :
CE ,ISO13485,FDA
Depth of Field :
3-100mm
Field Angle :
70+2
Battery :
Rechargeable Lithium Battery
Cycle life of battery :
>600times
Battery working time :
>400hrs
Warranty :
1 year
Image/ Video function :
Yes
Description

New Types Surgical Difficulty Airway intubation Reusable Video Laryngoscope

Specifications for the Video Laryngoscope

PARTS
Description
Technical Index
Machine
Screen
3 inch LCD
Resolution
960*480 (RGB)
Viewing angle
≥70º
Power
<2W
Display front and back rotation Angle
0 º~175 º
Weight
225g
Camera
Illuminance
≥3000 LUX
Resolution
1280*720 px
Image/Video function
Image/ Video function
Yes
Output
USB output, Easy to storage and establish image/video
Memory type
Micro SD card 32GB
Battery
Battery Type
Rechargable lithium battery
Capacity
3400mAh
Cycle life of battery
>600 times
Battery working time
>400min
Charging time
<2(hrs)
Charging Port
Micro USB
Power Adapter
Input
100-250V, 50 Hz.
Output
5V1A
Working

Condition
Temperature
-5℃~+50℃
Humidity
10%~90%
Air Pressure
860~1060hpa
Transport / Storage

Condition
Temperature
-10℃~50℃
Humidity
≤93%
Air Pressure
500~1060hpa

Features:

*Anti fog coating on distal lens
*Video/Photo function
*Battery rechargeable
*One button Only, Fast and simple operation
*360 °All sight LCD, no blind spot

Surgical medical equipment Reusable 5 size blades Video Laryngoscope

*Application range:
Routine and difficult tracheal intubation, Could be used for doctors in Anesthesia,
ICU/NICU/CCU, Operating Room, Emergency Rescue, Ambulance, ENT etc.
Clinical training and teaching of tracheal intubation.

NEW Medical Device Anti-fog Emergency Department Use Video Laryngoscope
Advantages

**Portable

Light weight, main unit is less than 350g. Disposable blade is vacuum packing. Excellent body design, easy to install or remove. It's ready to use in no time.

Packing and Delivery

Packing Size :400*95*360mm

Package Type :Carton ,Standard Export Packing for Ansthesia Video Laryngoscope With 5 blades.
