Specifications
Brand Name :
Haiye
Model Number :
HYHJ-KC
Certification :
CE, ISO13485, FDA, ISO9001
Place of Origin :
China
MOQ :
1 sets
Price :
USD 1000-1300 per set
Payment Terms :
T/T, Western Union, L/C
Supply Ability :
1000 set per year
Delivery Time :
5-8 work days
Packaging Details :
Anti-drop suitcase with foam protect in carton, Package size: 39.5X27X10 cm
Product :
Video laryngoscope
Model :
HYHJ-KC
Power :
Electricity
Material :
Stainless steel
MOQ :
1 set
weight :
2.3 kg
Camera Pixel: :
2 M
Display :
960*480
Screen :
3'' LCD color screen
Battery :
Rechargeable Li-ion
charging time :
4 hrs
Time of endurance :
6 hrs
Anti-fog :
Yes
After sales :
Online technical support
OEM :
Yes
Application :
endotracheal intubation
Description

Anesthesia Video Laryngoscope Reuseable For Difficult Airway Intubation With Enhanced Laryngoscope View

What is video Laryngoscope?

Videolaryngoscope (VL) is the latest frontiers in airway management. It serves as a valuable adjunct to facilitate intubation in a patient with known or suspected difficult airway. The standard VL has a digital camera, incorporated into the blade[1] and without the need of three-axis alignment and minimal swings in hemodynamics, the video laryngoscope provides an optimal glottic view, which is projected onto a screen where it can be visualized by both the anesthesia and surgical teams.

Specification of Anesthesia Video Laryngoscope
Description
Specification
Machine
Product name
video laryngoscope
Item weight≤472 g
Power
<2W
Screen
Screen size
3 inch LCD
Resolution
960*480 pixels (RGB)
Viewing angle
≥70º
Tilt angle(up/down)
0 º~135 º
Rotation angle(left/right)
0º～275º
Camera
Illuminance
≥3000 Lux
Resolution
2 mega or 1600*1200 pixels
Viewing angle
≥70º
Depth of field
3～100mm
Anti-fog
Yes
Image/Video function
Image/ Video/ Freeze frame function
Yes
Output
USB & AV output
Memory type
8GB Micro SD card
Battery
Battery Type
Rechargable Li-ion
Capacity
3400 mAh
Charging cycles
>800 times
Charging time
<4 hrs
Continuous working time
≥6 hrs
Power Adapter
Charging Port
Micro USB
Input
100-240V, 50 Hz.
Output
5V, 2000mA
Working condition
Temparature
5℃--40℃
Humidity
≤80%
Atmospheric pressure
860hpa～1060hpa

Main features of Anesthesia Video Laryngoscope
1.Clear view: Large depth of field, no blind area for intubation.
2.High resolution: 2 million pixels camera and 3" TFT clear color screen.
3.Intelligent: Built-in memory card is capable for data storage and output.
4.Faster: Unique anti-fog function, convenient and ready to use, no need for preheating.
5.Durable: High precision manufacturing process, ergonomic design handle with long service life.
6.Convenient: Portable laryngoscope with taking pictures, video recording and frame freezing function.
7.Optimization: Large capacity imported rechargeable Li battery provides up to 6 hrs continuous usage.
8.Safety: Disposable sterilized blades packaging to prevent cross infection for medical care personnel and patients.
9.Versatile: Integrated design applies for anesthesiology, ICU,pediatrics,emergency department and ambulance for clinical tracheal intubation.

Reusable Anesthesia Video Laryngoscope Airway Intubation With Enhanced View

Ansthesia Video Laryngoscope With 5 reuseable blades packages:

Packaging Details : Carton, Standard export packing for video laryngoscope
Package size: 415*110*345 cm
Gross weight: 3.2 kg
Standard equipment contain :
1x Main machine
5x Camera systems
5 x reusable stainless steel blades
1x Charger
1x Anti-drop suitcase with foam protect in carton
1x Operation manual and warranty card

Do you have clients who want a tracheal intubation solution with
better laryngoscope view?
Are you looking for a reusable video laryngoscope which could be sterilized?
Are you looking for a laryngoscope with versatile blades which could be applied in multiple health care or hospital departments?
How about a person help you to solve all the problems
and leave you to sit back and relax?
I am Larry from Haiye medical: a video laryngoscope reliable manufacturer.

Please kindly reach me BY larry@haiyemedical.com

OR WhatsApp: +86 132 8980 5658

Reusable Anesthesia Video Laryngoscope Airway Intubation With Enhanced View

FAQ

Q: Are you Manufacturer?

A: We are professional manufacturer of video Laryngoscope in China from 2013, now we mainly produce video laryngoscope with
disposable and reusable blade,welcome to visit our factory.

Q: What's your MOQ and OEM service available?

A: 1 sets as sample can accept, we offer OEM service and print logo as your requirement.

Q: Can we replace disposable and reusable blade?

A: main machine is the same, you can match our disposable or reusable blade freely.

Q: What's your warranty?

A: we offer 12 months warranty, within warranty change new machine, after warranty only pay produce cost.
