2.5Ton Heavy Duty Hard Anodizing Equipment 35 Micrometers Customize For Surface Treatment
2.5Ton Heavy Duty Hard Anodizing Equipment 35 Micrometers Customize For Surface Treatment
2.5Ton Heavy Duty Hard Anodizing Equipment 35 Micrometers Customize For Surface Treatment
2.5Ton Heavy Duty Hard Anodizing Equipment 35 Micrometers Customize For Surface Treatment
Specifications
Brand Name :
Hongshun
Model Number :
HS-6250-HA
Certification :
CCC/CE
Place of Origin :
Dongguan
MOQ :
1 set
Price :
$250,000 to $300,000
Payment Terms :
L/C,T/T
Supply Ability :
5 sets/month
Delivery Time :
75 days
Packaging Details :
film
Applications :
heavy-duty anodizing
Films Thickness :
35 micrometers
Water pressure :
0.3Mpa
Main power supply :
380±10%/50HZ
Electronic control system :
Omron PLC
Processing hardness :
350 HV
Description

A 2.5-ton Heavy-duty Hard Anodizing Processing Equipment, Capable Of Processing Films With A Thickness Of 35 Micrometers And A Hardness Of 350.

Hard Anodizing Processing Equipment Overview:

The 2.5-ton Heavy-duty Hard Anodizing Processing Equipment is engineered for robust aluminum surface treatment, handling large or heavy components with precision. This high-capacity system delivers exceptional hard anodized films, achieving consistent thicknesses up to 35 micrometers and impressive hardness of 350 HV—ideal for industrial parts requiring superior wear resistance, corrosion protection, and durability.
Designed to process heavy-duty aluminum components in aerospace, machinery, and automotive sectors, it features advanced process controls to ensure uniform film formation even on large or complex geometries. The automated workflow maintains strict parameters, guaranteeing reliable performance across batches.
Capable of handling 2.5-ton loads, it combines power with precision, enhancing component longevity and performance. For manufacturers needing heavy-duty anodizing with proven hardness and thickness, this equipment delivers industrial-grade results you can trust.

Material list for Hard Anodizing Processing Equipment:

device name

Ingredients specifications

place of production

brand

remarks

gangway

The main structure is made of A3 square tube and angle timber, and the structure is in the form of a landing.

domestic

Pedal 15mm fiberglass shed grid strong grid plate

Guangzhou

Guangzhou glass steel plant

filtering machine

Type: Precision single barrel filter magnetic suction filter machine material PP and SS cylinder

Dongguan

national treasure

Taiwan

pipe system

All pipe fittings are configured with standard products

All the water stop valves are double actuated PVC ball valves

Guangzhou

South Asia Taiwan

South Asia Plastics (Guangzhou) Co., LTD

commutator

Type: three-phase oil-cooled SCR control rectifier type

Output voltage: 0-25V (volt)

Output current: 3000A

Guangzhou

Jewel

Guangzhou

Exhaust air pipe

Main air pipe: 6MM PP plate is used, and the pipe diameter is Φ500mm

Suction hood: PP board is used, 8mm thick washing tower plate is 10mm thick

Hebei

Lida

Stainless steel tank

Material: SS304/3mm thick bending chamfer welding

Foshan

Tricyclic

Plastic tank

Material: PP15mm welding manufacturing

Taiwan

Lida

enter port

Whole machine rack

All the racks are made of A3 square tube, and the leading rail is made of stainless steel flat steel

Foshan

Respect to Yuan Hengyu

Portal crane

The body is made of SS steel plate, bent and welded

Foshan

Tricyclic

Italian worm gear electromagnetic brake motor is adopted

Italy

Simic

enter port

Electronic control system

The intermediate relay of Omron PLC series is selected in Japan

Shanghai

OMRON

Japan

AC contactor

Shanghai

Schneider

Germany

frequency transformer

Shanghai

Mitsubishi

Japan

Kunlun Tongtai touch screen

Beijing

Kunlun is in a state of flux

China

thermostat

Digital display temperature control and sensor

Shanghai

OMRON

Japan

cooling-water machine

The compressor is American Taikang compressor or French Myoyle

Guangdong

Dian Electric

For a complete technical solution of Hard Anodizing Processing Equipment, please contact me. We will customize the design based on your product technical requirements and factory layout.
