Customize Automated Anodizing Line 0.3Mpa Water Pressure For Building Materials Industry
Customize Automated Anodizing Line 0.3Mpa Water Pressure For Building Materials Industry
Customize Automated Anodizing Line 0.3Mpa Water Pressure For Building Materials Industry
Customize Automated Anodizing Line 0.3Mpa Water Pressure For Building Materials Industry
Specifications
Brand Name :
Hongshun
Model Number :
HS-6640-HA
Certification :
CCC/CE
Place of Origin :
Dongguan
MOQ :
1 set
Price :
$350,000 to $500,000
Payment Terms :
L/C,T/T
Supply Ability :
5 sets/month
Delivery Time :
75 days
Packaging Details :
film
Applications :
Building Materials Industry
Films Thickness :
15 micrometers
Water pressure :
0.3Mpa
Main power supply :
380±10%/50HZ
Electronic control system :
Omron PLC
Description

Anodizing Production Line For Building Materials Industry, Technologically Mature, Widely Used In Aluminum Profiles For Doors And Windows, Curtain Walls, Decorative Frames, Etc.

Anodizing Production Line Overview:

The Anodizing Production Line for the Building Materials Industry, backed by technologically mature processes, delivers superior surface treatment for aluminum building components. Widely trusted in construction sectors, it specializes in enhancing aluminum profiles used for doors, windows, curtain walls, and decorative frames, combining durability with aesthetic appeal.
This proven line creates a uniform, protective oxide layer that boosts corrosion resistance, weatherability, and color retention—critical for building materials exposed to outdoor elements. With mature technology ensuring consistent results, it handles diverse profile sizes and geometries, from standard frames to custom decorative designs.
Automated workflows guarantee batch-to-batch uniformity, while customizable finishes cater to varied architectural styles. Seamlessly integrating into building materials production, it reduces maintenance needs and extends product lifespan. For manufacturers supplying high-quality aluminum building components, this line offers reliable, industry-proven anodizing solutions.

Material list for Anodizing Production Line:

device name

Ingredients specifications

place of production

brand

remarks

gangway

The main structure is made of A3 square tube and angle timber, and the structure is in the form of a landing.

domestic

Pedal 15mm fiberglass shed grid strong grid plate

Guangzhou

Guangzhou glass steel plant

filtering machine

Type: Precision single barrel filter magnetic suction filter machine material PP and SS cylinder

Dongguan

national treasure

Taiwan

pipe system

All pipe fittings are configured with standard products

All the water stop valves are double actuated PVC ball valves

Guangzhou

South Asia Taiwan

South Asia Plastics (Guangzhou) Co., LTD

commutator

Type: three-phase oil-cooled SCR control rectifier type

Output voltage: 0-25V (volt)

Output current: 3000A

Guangzhou

Jewel

Guangzhou

Exhaust air pipe

Main air pipe: 6MM PP plate is used, and the pipe diameter is Φ500mm

Suction hood: PP board is used, 8mm thick washing tower plate is 10mm thick

Hebei

Lida

Stainless steel tank

Material: SS304/3mm thick bending chamfer welding

Foshan

Tricyclic

Plastic tank

Material: PP15mm welding manufacturing

Taiwan

Lida

enter port

Whole machine rack

All the racks are made of A3 square tube, and the leading rail is made of stainless steel flat steel

Foshan

Respect to Yuan Hengyu

Portal crane

The body is made of SS steel plate, bent and welded

Foshan

Tricyclic

Italian worm gear electromagnetic brake motor is adopted

Italy

Simic

enter port

Electronic control system

The intermediate relay of Omron PLC series is selected in Japan

Shanghai

OMRON

Japan

AC contactor

Shanghai

Schneider

Germany

frequency transformer

Shanghai

Mitsubishi

Japan

Kunlun Tongtai touch screen

Beijing

Kunlun is in a state of flux

China

thermostat

Digital display temperature control and sensor

Shanghai

OMRON

Japan

cooling-water machine

The compressor is American Taikang compressor or French Myoyle

Guangdong

Dian Electric

For a complete technical solution of Anodizing Production Line, please contact me. We will customize the design based on your product technical requirements and factory layout.
