How To Handle Small-scale Aluminum Alloy Anodizing By Integrated Equipment
How To Handle Small-scale Aluminum Alloy Anodizing By Integrated Equipment
Specifications
Brand Name :
Hongshun
Model Number :
JC-1683
Certification :
CCC/CE
Place of Origin :
Dongguan
MOQ :
1 set
Price :
$12,000 to $16,000
Payment Terms :
L/C,T/T
Supply Ability :
15 sets/month
Delivery Time :
35 days
Packaging Details :
wooden box
Application :
Small-scale Aluminum Alloy
Operating voltage :
220AC ±10%,50/60Hz
Environmental temperature :
-10°C to 40°C
Power consumption :
4KW
Maximum product size :
400*200*100mm
Dimensions :
1600*800*1800 mm
Description
How To Handle Small-scale Aluminum Alloy Anodizing By Integrated Equipment
With the integrated anodizing equipment, you can complete the anodizing process for small batches of aluminum alloy workpieces or for sample testing of new products at any time. The operation is simple and the cost is low. It helps with the development of your new products and efficiently meets the sample-making and small-order requirements of customers.
Operating Procedure

Now, let's introduce the usage method of this small anodizing machine:

First, turn on the 220V power supply. Then, turn on the refrigeration unit's power supply and set the temperature to 15 to 20 degrees. Next, turn on the heating chemical cleaning tank and the sealed tank. Set the temperature of the chemical cleaning tank to 90-100 degrees and the temperature of the sealed tank to 65 to 80 degrees. Start these operations half an hour in advance. Then, prepare the workpiece for anodizing.


The first step is to put it in the chemical cleaning tank for 30 seconds to 1 minute;

The second step is to put it in the water washing tank to clean the chemical solution, which is now very shiny;

The third step is to put it in the anodizing tank and turn on the anodizing switch. Set the anodizing time to 35 minutes. When the time is up, the workpiece has formed an oxide film;

The fourth step is to do a water wash;

The fifth step is to put it in the dyeing tank for dyeing. When the time is up, the workpiece has turned black;

The sixth step is to do another water wash;

The seventh step is to put it in the sealed tank for sealing holes;

The eighth step is to do another water wash, and the anodizing is completed.

Blow the water clean. This is a very beautiful black anodized finish.

How To Handle Small-scale Aluminum Alloy Anodizing By Integrated Equipment

Technical Specifications
Dimensions1600 × 800 × 1800 mm
Weight300 kg
Operating Voltage220AC ±10%, 50/60Hz ±1Hz
Power Consumption4KW
Maximum Product Size400 × 200 × 100 mm
Operating EnvironmentWorking temperature -10°C to 40°C
Safety Guidelines
  • Ensure proper ventilation in the operating environment
  • Immediately rinse eyes with clean water if contact occurs with oxidizing agents or chemical solutions
  • Exercise caution around high-temperature sealing and chemical polishing tanks to prevent burns
  • Disconnect power supply before maintenance or inspection
  • Disconnect power when machine will be unused for extended periods

About Dongguan Hongshun Automation Equipment Co., Ltd.
Located in Dongguan City, the global manufacturing capital, we are professional manufacturers of high-precision surface treatment equipment with comprehensive turnkey solutions.
Our Product Range
  • Ultrasonic cleaning equipment
  • Vacuum hydrocarbon cleaning machines
  • High-pressure spray cleaning machines
  • Spraying lines and passivation acid washing equipment
  • Anodizing and electroplating equipment
  • Industrial pure water machines and reclaimed water reuse equipment
  • Tunnel drying furnaces and peripheral equipment
We provide complete surface treatment projects integrating independent R&D, production, installation, training, and after-sales service with comprehensive quality management systems and strong technical support.
