Specifications
Brand Name :
Hongshun
Model Number :
HS-3121
Certification :
CCC/CE
Place of Origin :
Dongguan
MOQ :
1 set
Price :
$20,000 to $50,000
Payment Terms :
L/C,T/T
Supply Ability :
5 sets/month
Delivery Time :
75 days
Packaging Details :
film
Applications :
For Irregularly Shaped Aluminum Parts
safety standards :
OSHA, CE
Water pressure :
0.3Mpa
Main power supply :
380±10%/50HZ
Environmental temperature :
0℃~45℃ is most suitable
chillers :
20HP
Description
Semi-Automatic Anodizing Line With Manual Loading/Unloading For Irregularly Shaped Aluminum Parts
Semi-Automatic Anodizing Line Overview
Irregularly shaped aluminum parts (e.g., custom brackets, decorative components) often require manual handling to ensure proper treatment, and our Semi-Automatic Anodizing Line is designed for this. It features manual loading/unloading stations, where operators can carefully position parts on custom fixtures—preventing damage and ensuring full immersion in process tanks. The line’s core processes (anodizing, coloring, cooling) are automated: 3 anodizing tanks (15mm PP) with 25V-3000A rectifiers (adjustable current for different part sizes), 2 coloring tanks (3mm 304 stainless steel), and water-cooled chillers (temperature control ±3℃). Manual adjustment of immersion time is possible via the HMI, allowing operators to adapt to part complexity. The gantry cranes (SUS304, 100-250kg capacity) have manual override functions, enabling precise movement for parts with uneven surfaces. Basic safety features (limit switches, emergency stops) protect operators during manual handling. Constructed with durable materials (PP tanks, SUS304 cranes) and equipped with a simple exhaust system (removing fumes), the line is both reliable and safe. It supports small to medium batches (10-50 parts per cycle) and is easy to reconfigure for different part designs. For manufacturers processing irregularly shaped aluminum parts, this semi-automatic line balances automation efficiency with manual precision.
Equipment Working Conditions
Environmental temperature 0℃~45℃ is most suitable
Relative humidity less than or equal to 90%
Water pressure 0.3Mpa
Source of steam 0.2~0.5Mpa
Main power supply 380±10%/50HZ,25V-3000A rectifier, Refrigerator 22.5KW, Filter 8KW
Process Flow of Semi-Automatic Anodizing Line
Semi-Automatic Anodizing Line With Manual Loading/Unloading For Irregularly Shaped Aluminum Parts
For a complete technical solution of Semi-Automatic Anodizing Line, please contact us. We will customize the design based on your product technical requirements and factory layout.
After-sales Technical Services
  • 12 months free technical support and service (except consumables) with free maintenance for parts damaged by non-human operation errors
  • Lifetime paid technical support after warranty expiration
  • Chinese and English documentation provided for installation, operation and maintenance
  • Mechanical and electronic parts provided for one year
  • Warranty copy provided with effective date, coverage and contact information
  • On-site equipment monitoring by engineers within 6 months after delivery
