Specifications
Brand Name :
WSFIVIN
Model Number :
175EML
Certification :
ESR-5419 (ICC-ES)
Place of Origin :
CHINA
MOQ :
1000
Payment Terms :
T/T,L/C,D/P,D/A
Supply Ability :
10000PCS/DAY
Delivery Time :
7-15 days
Packaging Details :
10Pcs./Bundle 250/500Pcs. / Pallet
Product Name :
Astm C1063 Certified Self-furring Metal Lath With 0.013in Thickness
Key Words :
Self-Furring Metal Lath
Thinkness :
0.013in 0.35mm
Sample :
Free sample is available
Packing :
Pallet
Application :
Exterior wall protection, exterior wall processing
Type :
Perforated Mesh
Weight :
1.75LBS,2.5LBS,3.4LBS
Description

ASTM C1063 Certified Self-Furring Metal Lath with 0.013in Thickness

Overview
WSFIVIN’s 0.013" ASTM C1063-Certified Self-Furring Lath redefines lightweight reinforcement for modern plaster systems, combining rigorous compliance with innovative dimple geometry to reduce material costs by 22% while maintaining structural integrity. Engineered for residential retrofits and commercial interiors, this ultra-thin lath outperforms traditional 0.019" alternatives in mold-prone environments.

Core Features

1.Certified Precision

-Meets ASTM C1063 section 6.3 requirements for minimum 0.013" thickness verification.

-Pre-calibrated 3/8" dimples ensure 0.25" air gap accuracy across 97% of surface area.

2.Corrosion Defense

-Triple-layer electro-galvanizing (Z350 coating) resists alkaline plaster bleed-through.

-Passes 500-hour salt fog testing per ASTM B117 for coastal applications.

3.Installation Efficiency

-Anti-sag 28GA steel sustains vertical plaster loads up to 1.8psi.

-Pre-notched edges enable 15% faster fastener alignment in stud cavities.

Ideal Applications

-Historic Renovations: Lime plaster restoration in heritage buildings

-Hospital Wards: Hygienic wall systems with mold-inhibiting airflow

-Tile Backing: Crack prevention under ceramic/stone installations

-Fireproofing: Base layer for Type X gypsum assemblies

Ordering Benefits

-MOQ 500 sheets | Bulk discounts over 500 sheets

-Custom die-cutting for radius walls/columns

-PDF installation manuals with QR code access

CODE

Wt./Sq.Yd.(lbs)

Sheet Size

Standard Thickness

Pcs./Bundle

Pcs./Pallet

DML1.75

1.75 LBS

27” x 96”

0.35mm

10

500

DML2.5

2.5 LBS

27” x 96”

0.5mm

10

500

DML3.4

3.4 LBS

27” x 96”

0.638mm

10

250

FAQ

1. What is expanded metal lath used for?

It is mainly used as a base for stucco or plaster on walls, ceilings, and soffits. The mesh provides excellent keying for cementitious materials.

2. Does your product meet U.S. and Canadian standards?

Yes. Our expanded metal lath complies with ASTM C847 and CSA standards, and is ICC-ES(5419) certified, ensuring approval for a wide range of North American construction projects.

3. Do you offer different types and weights?

Yes. We offer various rib profiles, mesh patterns, and weights such as 1.75 lbs, 2.5 lbs, and 3.4 lbs per sheet to suit different application needs.

4. What is your MOQ and lead time?

Our minimum order is 2 pallets (total 1,000 sheets, 500 sheets per pallet). Typical lead time is 15–20 working days, depending on order volume and requirements.

5. How is the product packaged for export?

We use standard palletized packaging for safe and efficient container loading and unloading. Custom labels and weather-resistant wrapping are also available upon request.
