300kg SS Dryer Hopper PP Line
300kg SS Dryer Hopper PP Line
Specifications
Brand Name :
CHUQI
Model Number :
CQ-SPP120-6
Place of Origin :
CHINA
MOQ :
1SET
Price :
USD/RMB
Payment Terms :
T/T
Supply Ability :
10SETS
Delivery Time :
60DAYS
Packaging Details :
WOODEN BOX
Capacity :
300 kg
Material :
304 Stainless Steel
Drying temp :
0-120°C adjustable
Drying power :
12KW
Feeder power :
4KW
Moisture target :
≤0.1%
Companion :
Three-ingredient mixer
Continuous supply capability :
Yes
Description
300kg SS Dryer Hopper PP Line
Product Overview

Stable raw material supply is the lifeline of continuous production. This production line is equipped with a 300kg 304 stainless steel dryer hopper with an integrated automatic feeding device. The hopper has a built-in hot air drying module with adjustable temperature from 0-120°C and drying power of 12KW, ensuring PP material moisture content ≤0.1%, eliminating bubbles and silver streaks from the source.

The 300kg large capacity means that at maximum output, a single fill supports about 1.25 hours of continuous production; combined with automatic feeding, truly uninterrupted operation is achieved. 304 stainless steel is corrosion-resistant, easy to clean, and rust-free over long-term use, ensuring raw material purity.

Technical Specifications
Parameter Value
Hopper capacity 300 KG
Material 304 Stainless Steel
Drying temp. range 0 - 120°C adjustable
Drying power 12 KW
Feeder power 4 KW / 380V
Post-treatment moisture ≤ 0.1%
Key Features
  • Large capacity: 300kg stainless hopper reduces refill frequency and labor cost
  • Integrated drying: Hot air circulation removes moisture, preventing defects
  • Automatic feeding: Level sensor controls suction feeder for auto-replenishment
  • Durable material: 304 stainless steel is corrosion-resistant, easy to clean, rust-free
  • Safety design: Hopper lid has safety interlock to prevent misoperation
  • Energy efficient: Drying air is circulated to reduce heat waste
  • Precise temperature control: 0-120°C adjustable for different materials
  • Easy maintenance: Bottom discharge port for residual material removal
  • Strong compatibility: Seamless integration with three-ingredient mixer
  • Continuous supply: Large capacity + auto feeding ensures line never starves
Frequently Asked Questions
Q: How long can a full 300kg hopper run?
A: At maximum output of 240 kg/h, a full hopper lasts about 1.25 hours. The automatic feeder continuously replenishes, enabling truly uninterrupted production.
Q: What is the recommended drying temperature?
A: For standard PP, 80-100°C is recommended. The drying function must run continuously because even initially dry material absorbs moisture in the workshop environment. Turning off drying leads to moisture-related defects.
Q: Does the hopper need regular cleaning?
A: Cleaning is recommended every 200-300 tons of production or when switching colors/modified materials. A discharge port at the bottom facilitates removal of residual material.
