Prefab Steel Structure Warehouse with Large Span Design
Prefab Steel Structure Warehouse with Large Span Design
Prefab Steel Structure Warehouse with Large Span Design
Prefab Steel Structure Warehouse with Large Span Design
Prefab Steel Structure Warehouse with Large Span Design
Prefab Steel Structure Warehouse with Large Span Design
Prefab Steel Structure Warehouse with Large Span Design
Prefab Steel Structure Warehouse with Large Span Design
Prefab Steel Structure Warehouse with Large Span Design
Prefab Steel Structure Warehouse with Large Span Design
Prefab Steel Structure Warehouse with Large Span Design
Prefab Steel Structure Warehouse with Large Span Design
Specifications
Brand Name :
YDX
Model Number :
YDX-14
Certification :
CE ISO SGS
Place of Origin :
CHINA,QINGDAO
MOQ :
50-10000 square meters
Price :
$35.00-$63.00
Payment Terms :
T/T
Supply Ability :
10000 tons/month
Delivery Time :
20-30 works days
Packaging Details :
Exported standard packing
Window :
Aluminum Alloy Window
Technique :
Hot Rolled
Frame :
Steel Structure
Drawing :
CAD, TEKLA, 3D Model, PKPM, BIM
Connection :
Welded Or Bolted
Dimension :
Customers' Requirement
Purlin :
C Section or Z Section, Q235
Features :
Steel Frame Warehouse
Design :
Customizable
Intensity :
High Intensity
Description

Prefab Steel Structure Warehouse Workshop Large Span Industrial Building

Product Description
Our steel structure warehouse is a modern storage solution offering numerous advantages for various industrial needs. These prefabricated buildings provide exceptional flexibility compared to traditional concrete warehouses, allowing for easy transformation and expansion to meet evolving business requirements.
The steel construction creates large, column-free indoor spaces, maximizing storage capacity. Built with durable Q355B carbon structural steel, these warehouses withstand heavy loads and seismic activity while offering a 50-year service life. The material's recyclability makes it an environmentally sustainable choice, with quick construction times minimizing environmental impact.
Prefab Steel Structure Warehouse with Large Span Design
Multi-story Steel Structure Applications
Multi-story steel structures are increasingly popular for commercial and residential projects due to their strength and versatility. The inherent strength of steel allows for taller buildings with fewer support columns, creating more usable space and architecturally appealing designs.
These structures demonstrate excellent resistance to natural disasters including earthquakes and hurricanes. Steel's flexibility enables it to absorb impact from strong winds, while its durability ensures long-term performance with minimal maintenance requirements.
Product Application
Light Frame Steel Construction Hangar Design Prefabricated Steel Structure Factory Building Workshop warehouse
A pre-engineered steel building is a modern technology where the complete designing is done at the factory and the building components are brought to the site and then fixed/jointed at the site, all is bolt connection, no need any welding!
An efficiently designed pre-engineered building can be lighter than the conventional steel buildings by up to 30%. Lighter weight equates to less steel and potential price savings in structural framework.
SPECIFICATION FOR STEEL STRUCTURE BUILDING
Main Steel Frame Steel Column & Beam 1. Material: Q345B (S355JR) or Q235B(S235JR)/ Welded/Hot Rolled H section steel
2. Surface: Hot Dip Galvanized or Painted;
3. Connection: All Bolts Connection;
Supporting System Roof Purlin C or Z Section Steel, Q235B
Wall Purlin C or Z Section Steel, Q235B
Bracing Steel Rod, Q235B
Cross Support Steel Rod, Q235B
Column Support Angle Steel; Steel Rod; Q235B
Angle Brace Angle steel,Q235B
Tie Bar Steel Pipe,Q235B
Roof & Wall System 1. Single Colorful Corrugated Steel Sheet;
Thickness: 0.3-0.8mm
2. Sandwich Panel with EPS, Rock Wool, Fiberglass,PU;
Thickness: 50-150mm;
Accessories Door Sliding; Rolled Up Door (Manual/Auto)
Window Aluminum Alloy; PVC;
Downspout PVC pipe;
Gutter Galvanized Steel Sheet; Stainless Steel
Ventilator Stainless Steel Turbine Ventilator
Skylight Belt FRP or PC semi-transparent Skylight Belt
Flash Color Steel Sheet
Fittings Anchor Bolt; High Strength Bolt; Standard Bolt, Self-tapping nail etc
Steel structure building
1. Primary Framing Box beam column, cross steel column, H-shaped steel column, steel beam
2. Secondary Framing Galvanized Z and C sections purlin
3. Roof and Wall panels Steel sheet and insulated sandwich panels (EPS, fiberglass wool and PU).
4. Steel Decking Floor Galvanized steel decking board
5.Structural subsystem Divider, gutter, awning, partition wall
6.Mezzanines, Platforms Painted or galvanized H beam
7.Other Building Accessories Sliding doors, roll up doors, aluminium windows, louvers, etc.
Service Life 50-70years support steel angle, steel pipe, steel round
Place of Origin Qingdao,Shandong,China Application workshop, warehouse, poultry house,garage etc
Grade Q235B, Q355B or as per customer's need Bolt Grade M20, M16, M14 etc
Connection intensive bolt, ordinary bolt Window PVC steel or aluminum alloy
Downspout PVC pipe or as per customer's request Door sliding or rolling door
Purlin C/Z shape profile Panel EPS/PU/fiber glass/rock wool
Main Frame Welded or hot rolled H-shaped steel, columns, beams, box beams and columns
Drawings & Quotation:
(1) Customized design is welcomed.
(2) In order to promise an accurate quotation and drawings, please let us know the length, width, eave height and local weather.We will quote for you promptly.
Prefab Steel Structure Warehouse with Large Span Design
Packing and Shipping
Prefab Steel Structure Warehouse with Large Span Design
Request a Quote
Please provide the following information for an accurate quotation:
Location (where will it be built?) _____country, area
Size: length*width*height _____mm*_____mm*_____mm
Wind load (max. wind speed) _____kn/m2, _____km/h, _____m/s
Snow load (max. snow height) _____kn/m2, _____mm
Anti-earthquake _____level
Brickwall needed or not If yes, 1.2m high or 1.5m high
