Specifications
Brand Name :
YDX
Model Number :
YDX-DS5
Certification :
CE ISO SGS
Place of Origin :
CHINA,QINGDAO
MOQ :
10-10000 square meters
Price :
$30.00-$65.00
Payment Terms :
T/T
Supply Ability :
10000 tons/month
Delivery Time :
20-30 works days
Packaging Details :
Exported standard packing
Main Frame: :
Q355 Q235
Window: :
PVC, Aluminum Windows
Door： :
Sliding Door, Rolling Door
Wall & Roof: :
Sandwich Panel; Color Steel Sheet
Secondary Structure： :
Purlin; Brace, Knee Brace Etc
Cladding: :
PU/Rock Wool/Fiberglass/EPS
Structure Type :
Frame
Frame Type :
Steel Frame
Earthquake Resistance :
Strong
Windows :
Aluminum
Seismic Design :
High Seismic Zone
Installation Time :
Short
Aesthetics :
Modern
Construction Type :
Frame
Cost :
Moderate
Product Resistance :
Corrosion Resistant
Finish :
Galvanized/Painted/Cladding
Roof :
Glass Wool, EPS, PU
Product Fire Resistance :
Fireproof
Door :
Sliding Door or Rolling Door
Description

ISO Steel Structure Workshop EPS Panel Prefabricated Steel Structure H Shaped

Product Specifiactions

Prefabricated steel workshop is combined by steel structure frame, roof and wall steel cladding, aluminium windows & doors, etc. Steel structure frame refers steel columns, beams, tie bars, bracing, C/Z purlin, etc.

Product Application
Light Frame Steel Construction Hangar Design Prefabricated Steel Structure Factory Building Workshop warehouse
A pre-engineered steel building is a modern technology where the complete designing is done at the factory and the building components are brought to the site and then fixed/jointed at the site, all is bolt connection, no need any welding!
An efficiently designed pre-engineered building can be lighter than the conventional steel buildings by up to 30%. Lighter weight equates to less steel and potential price savings in structural framework.
SPECIFICATION FOR STEEL STRUCTURE BUILDING
Main Steel Frame Steel Column & Beam 1. Material: Q345B (S355JR) or Q235B(S235JR)/ Welded/Hot Rolled H section steel
2. Surface: Hot Dip Galvanized or Painted;
3. Connection: All Bolts Connection;
Supporting System Roof Purlin C or Z Section Steel, Q235B
Wall Purlin C or Z Section Steel, Q235B
Bracing Steel Rod, Q235B
Cross Support Steel Rod, Q235B
Column Support Angle Steel; Steel Rod; Q235B
Angle Brace Angle steel,Q235B
Tie Bar Steel Pipe,Q235B
Roof & Wall System 1. Single Colorful Corrugated Steel Sheet;
Thickness: 0.3-0.8mm
2. Sandwich Panel with EPS, Rock Wool, Fiberglass,PU;
Thickness: 50-150mm;
Accessories Door Sliding; Rolled Up Door (Manual/Auto)
Window Aluminum Alloy; PVC;
Downspout PVC pipe;
Gutter Galvanized Steel Sheet; Stainless Steel
Ventilator Stainless Steel Turbine Ventilator
Skylight Belt FRP or PC semi-transparent Skylight Belt
Flash Color Steel Sheet
Fittings Anchor Bolt; High Strength Bolt; Standard Bolt, Self-tapping nail etc


ISO Steel Structure Workshop EPS Panel Prefabricated Steel Structure H Shaped


ISO Steel Structure Workshop EPS Panel Prefabricated Steel Structure H Shaped

Product Description
Our multiple span prefabricated steel structure buildings are engineered for industrial applications including warehouses, workshops, and cold storage facilities. The steel construction offers superior strength, durability, and design flexibility.
Steel structures provide exceptional advantages for industrial construction:
  • High tensile strength to withstand heavy loads and demanding conditions
  • Fully customizable designs to meet specific operational requirements
  • Rapid construction with prefabricated components reducing labor costs
  • Environmentally sustainable material with recyclable properties
  • Corrosion-resistant treatments available for humid environments

ISO Steel Structure Workshop EPS Panel Prefabricated Steel Structure H Shaped

Installation Support:
We provide comprehensive installation support including:
  • Detailed construction drawings prior to installation
  • On-site engineering guidance for proper assembly


ISO Steel Structure Workshop EPS Panel Prefabricated Steel Structure H Shaped


ISO Steel Structure Workshop EPS Panel Prefabricated Steel Structure H Shaped

Why Choose Our Steel Structures:
  • Cost-effective: Professional design reduces construction time and material costs
  • Quality assurance: CE, Aisc, SGS, BV, ISO, GB certified manufacturing
  • Environmental benefits: Specialized cladding materials provide excellent insulation; recyclable materials
  • Production capacity: 50,000 square meters per month production capability
  • Custom solutions: Tailored designs to meet specific project requirements
Packing & Loading:

All the structure components, panels,bolts and sort of accessories will bewell packed with standard package suitable ocean transportation and loaded into 40’HQ.

All the products are loaded at the loading site of our factory using crane and forklift by our skilled workers,who will prevent the goods to be damaged.

ISO Steel Structure Workshop EPS Panel Prefabricated Steel Structure H Shaped
Frequently Asked Questions:
Are you a manufacturer or trading company?
We are a manufacturer with our own factory in Qingdao, China. Customers are welcome to visit our production facilities.
Is your price competitive?
We offer the best price/quality ratio in the market, with strict quality control throughout production.
Do you provide installation support?
We provide detailed installation drawings and can send engineers or a full installation team upon request.
What is your delivery time?
Typical delivery time to nearest Chinese seaport is 40 days after receiving deposit, depending on order quantity.
1 Location (where will be built?) _____country, area
2 Size: length*width*height _____mm*_____mm*_____mm
3 wind load (max. wind speed) _____kn/m2, _____km/h, _____m/s
4 snow load (max. snow height) _____kn/m2, _____mm
5 anti-earthquake _____level
6 brickwall needed or not If yes, 1.2m high or 1.5m high
7 thermal insulation If yes, EPS, fiberglass wool, rockwool, PU sandwich panels will be suggested; . if not, the metal steel sheets will be ok. The cost of the latter will be much
lower than that of the former
8 door quantity & size _____units, _____(width)mm*_____(height)mm
9 window quanity & size _____units, _____(width)mm*_____(height)mm
10 crane needed or not If yes, _____units, max. lifting weight____tons; max. lifting height _____m
