11 Spindles Glass Edging Machine Vibration Free 6960*1000*2600mm
11 Spindles Glass Edging Machine Vibration Free 6960*1000*2600mm
Specifications
Model Number :
ST-272E
Wheels :
11
MOQ :
1
Delivery Time :
30 working days
Total dimension :
6960*1000*2600mm
Price :
$12500-$15000USD/SET
Total weight :
3300KG
Certification :
CB,CE, RoHS, ISO9001
Working speed :
0.6-8.0m/min
Payment Terms :
T/T
Glass thickness :
3-20mm
Place of Origin :
China
Total power :
27kw
Supply Ability :
60Set each month
Brand Name :
FOSHAN STAR
Name :
Glass Edging Machine
Packaging Details :
Protective Film
Description
11 Spindles Glass Straight Line Edging Machine
Machine Introduction

1. This 11‑spindle straight‑line glass edger grinds and polishes the bottom edge and chamfer of flat glass. A specially‑made telescopic platen accommodates different glass thicknesses; the machine runs stably and is simple to operate.

2. Parallel‑moving front rails allow precise glass‑thickness adjustment. The chamfer wheel with pallet support prevents grinding vibration, and the main transmission adopts frequency‑conversion speed regulation.

3. A unique vertically adjustable input conveyor rack enables grinding‑amount adjustment via handwheel, with real‑time digital display of the grinding removal.

Product Advantage
  • Inverter‑driven main transmission, vibration‑free smooth running and low noise across full speed range
  • Digital indicator for glass thickness
  • Manual lubrication for grinding‑head slides for easy maintenance
  • Dual‑speed motor for the last bottom‑edge polishing spindle
  • 4‑layer waterproof brushes, simple replacement
  • Upgraded front beam with exclusive linear platens for convenient overhaul
  • Heavy‑duty cast‑iron front & rear rails, deformation‑resistant
  • Integral cast‑iron bed and supporting pillars
  • Precision‑processed dovetail carriage, zero‑gap, vibration‑free working
  • Highly elastic, heat‑resistant waterproof brushes
  • Famous‑brand spare parts: Lobster splints & Hangzhou Donghua chains
Technical Parameters
Parameter Value
Wheels 11
Working speed 0.6-8.0m/min
Max. arris width 2.5mm
Min. glass size 80*80mm
Glass thickness 3-20mm
Total power 27kw
Total dimension 6960*1000*2600mm
Total weight 3300kg
