3-19mm Float Glass CNC Cutting Machine , Decorative Glass Machine With Two Worktables
3-19mm Float Glass CNC Cutting Machine , Decorative Glass Machine With Two Worktables
Specifications
Model Number :
3826
Applicable Glass Type :
Float Glass
Place Of Origin :
FOSHAN
Delivery Time :
30-50
Rack :
Atlantic Germany
Production Capacity :
30-50 Set/month
MOQ :
1
Cutting Speed :
0-30 M/min
Certification :
CE/ISO/RoHS
Cutting Glass :
Breaking Glass
Price :
25580USD
Transport Package :
Seaworthy Package
Place of Origin :
CHINA
Electric Power :
380V/50Hz/220V/50Hz
Payment Terms :
T/T
Air Pressure :
0.6-0.8MPa
Brand Name :
Glass Cutting Machine
Name :
Glass CNC Cutting Machine
Packaging Details :
Protective film
Description
CNC glass cutting machine, with two worktables, suitable for cutting glass with a thickness of 3-19mm.
Product Overview
ST-YTJ3829 intelligent glass loading and cutting machine consists of two systems: loading and cutting machine
and air-floating breaking table. It integrates automatic loading, automatic optimization layout, automatic
labeling, automatic cutting, automatic transportation and air-floating breaking table, and realizes automatic
operation of glass cutting process. The machine is equipped with power walking wheels, which can be
controlled by remote control in the working area for easy shifting. The machine can realize straight and special-
shaped cutting of glass, and is suitable for architectural glass, furniture glass, craft glass, decorative glass,
cabinet glass, glass mirror, etc.
Technical Specifications
ParameterSpecification
Voltage380V/50Hz
Cutting MethodBreaking Glass
Maximum Cutting Area3660*2800mm
Diagonal Precision≤±0.15mm
Mechanical Test ReportProvided
Air Pressure0.6-0.8MPa
RackAltantic Germany
Color DesignCustomized
Transport PackageSeaworthy Package
Cutting Speed0-30 M/min
Applications

Model 3829 from FOSHAN is a state-of-the-art glass sheet cutting machine with a production capacity of 30-50 sets per month. Ideal for businesses requiring reliable and efficient glass processing solutions, it handles large glass panels up to 3660*2800mm, making it suitable for both small-scale workshops and large manufacturing plants.

Operating on 380V/50Hz or 220V/50Hz power specifications, this machine delivers exceptional diagonal precision of ≤±0.15mm, ensuring highly accurate and clean cuts for applications requiring exact dimensions and flawless edges in architectural glass production, automotive glass manufacturing, and custom glass fabrication.

Customization Options

Our Model 3829 CNC glass cutting machine offers comprehensive customization services to meet specific glass fabrication needs. We provide customizable color design options to match your brand or workspace aesthetics, with adjustable cutting speeds from 0 to 30 meters per minute and efficient operation under 0.6-0.8MPa air pressure.

Each machine is packaged with seaworthy transport packages to ensure safe delivery worldwide, providing reliable, precise, and customizable cutting solutions for all your glass fabrication projects.

Technical Support & Services
  • Installation and Setup: Ensure installation on a stable, level surface in a clean environment following user manual instructions
  • Operation: Use only for intended glass cutting purposes with appropriate safety gear (gloves, eye protection)
  • Maintenance: Regular cleaning of cutting surfaces and components, lubrication of moving parts, and inspection/replacement of cutting wheels
  • Troubleshooting: Consult user manual for issues like inaccurate cuts, unusual noises, or malfunctions
  • Technical Support: Available guidance on installation, operation, and maintenance
  • Warranty and Service: Limited warranty covering manufacturing defects with authorized service centers for repairs and replacement parts
Packing & Shipping

The Glass Cutting Machine is carefully packaged with protective foam inside a sturdy, custom-designed cardboard box to prevent damage during transit. Shock-absorbing materials and tight sealing protect against dust and moisture.

We offer multiple tracked and insured shipping options, including standard and expedited delivery services. Please inspect packages upon receipt and report any visible damage immediately to our customer service team.
3-19mm Float Glass CNC Cutting Machine , Decorative Glass Machine With Two Worktables
3-19mm Float Glass CNC Cutting Machine , Decorative Glass Machine With Two Worktables
3-19mm Float Glass CNC Cutting Machine , Decorative Glass Machine With Two Worktables
3-19mm Float Glass CNC Cutting Machine , Decorative Glass Machine With Two Worktables
3-19mm Float Glass CNC Cutting Machine , Decorative Glass Machine With Two Worktables
3-19mm Float Glass CNC Cutting Machine , Decorative Glass Machine With Two Worktables
3-19mm Float Glass CNC Cutting Machine , Decorative Glass Machine With Two Worktables
3-19mm Float Glass CNC Cutting Machine , Decorative Glass Machine With Two Worktables
3-19mm Float Glass CNC Cutting Machine , Decorative Glass Machine With Two Worktables
3-19mm Float Glass CNC Cutting Machine , Decorative Glass Machine With Two Worktables
3-19mm Float Glass CNC Cutting Machine , Decorative Glass Machine With Two Worktables

Frequently Asked Questions
What is the MOQ?
1 SET
What is the best price?
The price depends on machine size, model, and specifications.
What is the delivery time?
Usually within 30-60 days, depending on machine model and voltage requirements.
What about warranty?
We supply one year warranty period with lifetime technical support and service.
How is your after-sale service?
Online remote service, on-site engineer installation and training, and 24/7 support.
Where do you sell? Do you have experience in these countries?
We export to America, Europe, Middle East, Asia, and more with 20 years of export experience and certifications including CB, CE, RO, HS, and ISO9001.
