ASTM A276 Hot Rolled 2205 Duplex Stainless Steel Bar Stock 10mm For Marine Applications
ASTM A276 Hot Rolled 2205 Duplex Stainless Steel Bar Stock 10mm For Marine Applications
Specifications
Model Number :
2205
Standard :
ASTM A276, ASTM A479, EN 10088
Certification :
ISO,SGS,CE,BIS
Advantage :
High Corrosion Resistance
Place of Origin :
China
Section Shape :
Round
MOQ :
1Ton
Delivery Time :
8 ~ 14 days
Product name :
2205 Duplex Stainless Steel Bar
Payment Terms :
L/C,D/A,D/P,T/T,Western Union
Grade :
200 series
Price :
negotiable
Shape :
Round
Packaging Details :
Standard Package
Supply Ability :
Adequate production
Color :
Customer's Request
Brand Name :
JUDE STEEL
Type :
Round
Description
ASTM A276 Hot Rolled 2205 Duplex Stainless Steel Bar Stock 10mm For Marine Applications

ASTM A276 Hot Rolled 2205 Duplex Stainless Steel Bar Stock 10mm is a high-strength duplex stainless steel bar combining the excellent corrosion resistance of austenitic stainless steel with the superior mechanical strength of ferritic stainless steel. With outstanding resistance to pitting, crevice corrosion, and stress corrosion cracking, 2205 duplex stainless steel is widely used in marine engineering, offshore platforms, oil & gas, chemical processing, and desalination plants.

Manufactured in accordance with ASTM A276, our 2205 duplex stainless steel bars provide exceptional durability, long service life, and reliable performance in aggressive chloride-containing environments.

Key Attributes
Item Specification
Product Name ASTM A276 Hot Rolled 2205 Duplex Stainless Steel Bar
Grade 2205 Duplex Stainless Steel
UNS S32205 / S31803
EN 1.4462
Standard ASTM A276, ASTM A479, EN 10088
Process Hot Rolled
Shape Round Bar (Square, Flat & Hex Bar Available)
Diameter 10 mm (Custom Sizes Available)
Length 3m, 6m, or Customized
Surface Finish Black, Peeled, Bright, Ground, Polished
ASTM A276 Hot Rolled 2205 Duplex Stainless Steel Bar Stock 10mm For Marine Applications
Physical Properties
Property Value
Density 7.80 g/cm³
Melting Range 1350–1450°C
Elastic Modulus 200 GPa
Thermal Conductivity 19 W/m·K (20°C)
Specific Heat 500 J/kg·K
Electrical Resistivity 0.85 μΩ·m
Coefficient of Thermal Expansion 13.0 × 10⁻⁶/K
Mechanical Properties
Property Typical Value
Tensile Strength ≥620 MPa
Yield Strength ≥450 MPa
Elongation ≥25%
Hardness ≤290 HB
Chemical Composition
Element Content (%) Role in Alloy Performance
Chromium (Cr) 22.0–23.0 Provides superior corrosion and oxidation resistance
Nickel (Ni) 4.5–6.5 Enhances toughness and stress corrosion cracking resistance
Molybdenum (Mo) 3.0–3.5 Increases pitting and crevice corrosion resistance in chloride environments
Nitrogen (N) 0.14–0.20 Improves strength and pitting resistance without sacrificing ductility
Manganese (Mn) ≤2.0 Deoxidizer — improves hot workability
Silicon (Si) ≤1.0 Enhances oxidation resistance at elevated temperatures
Carbon (C) ≤0.03 Tightly controlled to prevent carbide precipitation and intergranular corrosion
Phosphorus (P) ≤0.03 Trace impurity — kept low to maintain toughness
Sulfur (S) ≤0.02 Trace impurity — controlled for optimal weldability
Applications

The 10 mm ASTM A276 2205 duplex stainless steel bar is widely used in:

  • Marine and offshore engineering
  • Shipbuilding
  • Oil & gas equipment
  • Chemical processing plants
  • Heat exchangers
  • Pressure vessels
  • Pumps and valves
  • Fasteners and shafts
  • Desalination systems
  • Structural components in corrosive environments
Why Choose Our 2205 Duplex Stainless Steel Bars?
Premium Raw Materials

We use high-quality raw materials from certified steel mills to ensure excellent corrosion resistance, strength, and consistency.

Strict Quality Control

Every batch undergoes comprehensive inspection, including:

  • Chemical composition analysis
  • Mechanical property testing
  • Ultrasonic testing (UT)
  • PMI (Positive Material Identification)
  • Dimensional inspection
  • Surface quality inspection

Mill Test Certificate (EN 10204 3.1) and third-party inspection are available upon request.

Complete Size Range
  • Diameter: 6 mm–500 mm
  • Standard lengths: 3 m, 6 m
  • Custom cutting services
  • OEM and CNC machining support
Fast Delivery

With a large inventory of duplex stainless steel bars, we ensure quick shipment and stable supply for both small and bulk orders.

Frequently Asked Questions (FAQ)
What is 304 Stainless Steel Round Bar?

304 Stainless Steel Round Bar is an austenitic stainless steel bar with excellent corrosion resistance, weldability, and machinability. It is widely used in machinery, construction, food processing, and industrial manufacturing.

What is the difference between bright, ground, and polished stainless steel rods?
  • Bright Rod: Cold drawn with a smooth finish and precise dimensions.
  • Ground Rod: Precision ground for tighter tolerances and superior roundness.
  • Polished Rod: Mechanically polished to achieve a decorative or mirror-like surface.
What standards do your products meet?

Our products comply with ASTM A276, ASTM A479, EN 10088, and JIS G4303, and are supplied with EN 10204 3.1 Mill Test Certificates upon request.

Do you offer custom machining services?

Yes. We provide cutting, CNC turning, milling, drilling, threading, grinding, polishing, and other custom processing services based on customer drawings.
