1200mm Belt Color Sorter QC Inspection Colour Sorter Machine
1200mm Belt Color Sorter QC Inspection Colour Sorter Machine
Specifications
Brand Name :
PHOENIX
Model Number :
QC Inspection Machine
Place of Origin :
Hefei
MOQ :
1
Price :
Price Negotiable
Payment Terms :
,L/C,D/A,D/P,T/T,Western Union,MoneyGram
Delivery Time :
5-8 work days
Mode :
QC4
Belt Width (mm) :
1200
Air Nozzle :
256
Air Pressure (MPa) :
0.6~0.8
Air Consumption (m³/min) :
<3.6
Voltage :
220V~50/60Hz
Description
AI Quality Inspection Machine: Post-Regular Sorting, Smart-Driven Ultimate Quality Control, Replacing Traditional Manual Inspection
Technical Features
  • Tailored "Ultimate Quality Guardian" for dehydrated vegetables
  • Compact single-belt sorting system with quick-install design
  • Innovative high-capacity 3-layer vibratory feeder, which evenly spreads dehydrated vegetables into a single layer to significantly reduce material overlap
  • Food-grade stainless steel structure, compliant with global food safety and hygiene standards
  • Sealed scanning and control boxes, providing high-level dust protection for the machine
  • Quick belt change design, facilitating routine maintenance and cleaning to meet higher food safety and hygiene requirements
  • Integrated field-proven Dust Control System, ensuring operational stability and performance consistency while significantly reducing downtime risks
AI-Powered 4-in-1 Multispectral Inspection System
  • Proprietary AI deep learning algorithm, which continuously optimizes defect recognition capabilities based on new samples
  • Ultra-high-resolution RGB camera system
  • High-intensity LED illumination system
  • Optional NIR camera system or HSI camera system

Ultra-high-precision detection of subtle contaminants in dehydrated vegetables; identifies impurities with abnormal features (color, size, shape, texture), including:

  • Hair
  • Fibers
  • Low-density plastics
High-Performance Rejection System
  • Optional Air Nozzle Rejection System and Drop Flap Rejection System
  • Engineered with zero-tolerance rejection design, enabling reliable operation to achieve "ultimate quality control" objectives

1200mm Belt Color Sorter QC Inspection Colour Sorter Machine

1200mm Belt Color Sorter QC Inspection Colour Sorter Machine

1200mm Belt Color Sorter QC Inspection Colour Sorter Machine

1200mm Belt Color Sorter QC Inspection Colour Sorter Machine

Specifications
Model Belt Width (mm) Air Nozzle Air Pressure (MPa) Air Consumption (m³/min) Voltage Power (kW) Dimension (mm) Unpacked Weight (kg)
QC4 1200 256 0.6~0.8 <3.6 220V~50/60Hz 3.9 4102*2443*2125 1097
