600mm Belt Potato Grading Equipment For Fruits And Vegetables
600mm Belt Potato Grading Equipment For Fruits And Vegetables
Specifications
Brand Name :
PHOENIX
Model Number :
HD AI Optical Sorter
Place of Origin :
Hefei
MOQ :
1
Price :
Price Negotiable
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Delivery Time :
5-8 work days
Model :
HD2
Belt Width (mm) :
600
Air Nozzle :
256
Air Pressure (MPa) :
0.6~0.8
Description
HD AI Optical Sorter AI Powered High-precision Defect Removal And Quality Grading With Industry-leading Accuracy For Dehydrated Vegetables
Technical Features
  • Tailored Superior Sorting Solution for Dehydrated Vegetables
  • Compact dual-belt sorting system with quick-install and simultaneous resorting design
  • Primary sorting occurs on higher-level belt and aggressively removes all potential defects (may include false rejects)
  • Secondary sorting on lower-level belt receives rejects from primary sorting for false-reject recovery
  • Optional innovative high-capacity 2-layer vibratory feeder evenly distributes dehydrated vegetables into a single layer to minimize overlapping
  • Food-grade stainless steel structure complies with global food safety and hygiene standards
  • Sealed scanning and control boxes provides machine with high-level dust protection
  • Field-proven Dust Control System integrated maintains high operation reliability and performance consistency, and minimizes downtime
  • Quick belt change for convenient routine maintenance and cleaning, meeting higher food safety and hygiene standards
  • Modular design of belt width from 600 to 1200mm (600/1200) provides processors more flexibility
AI Powered 4-in-1 Multispectral Inspection System
  • Proprietary AI Deep Learning algorithms continuously improve defect recognition based on new samples
  • High-Resolution RGB Camera System
  • High-Intensity LED Illumination System
  • Optional InGaAs-SWIR Camera System
  • Optional UV Fluorescence Camera System
  • Marketing-leading precision detection to a wide range of defects of dehydrated vegetables by color, size, shape and texture features:
  • Color Defects: Browning, discoloration, charred spots, mold, skin residues
  • Shape Defects: Broken fragments, clumped pieces, deformed shapes, oversized, undersized
  • Drying Defects: Uneven dehydration, sugar crystallization, rehydration stains
  • Foreign Material Contamination: plastic/rubber fragments
  • Biological Contamination: Microbial colonies
High-Performance Ejector System
  • Engineered for enhanced durability, optimized speed and air consumption
  • Accurate rejection and reliable performance at high-capacity sorting
  • Significant reduction in false rejection rate and total cost of ownership

600mm Belt Potato Grading Equipment For Fruits And Vegetables

Specifications
Model Belt Width (mm) Air Nozzle Air Pressure (MPa) Air Consumption (m³/min) Voltage Power (kW) Dimension (mm) Unpacked Weight (kg)
HD2 600 256 0.6~0.8 <2.0 220V~50/60Hz 6.4 3641×1540×2804 1376
HD4 1200 512 0.6~0.8 <4.1 220V~50/60Hz 7.9 3641×2140×2804 1917
