Non Ferrous Metals Sorter Machines For Recovering Copper , Aluminum
Non Ferrous Metals Sorter Machines For Recovering Copper , Aluminum
Non Ferrous Metals Sorter Machines For Recovering Copper , Aluminum
Non Ferrous Metals Sorter Machines For Recovering Copper , Aluminum
Specifications
Brand Name :
PHOENIX
Model Number :
HDF-R AI-RGB Sorter
Place of Origin :
Hefei
MOQ :
1
Price :
Price Negotiable
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Delivery Time :
5-8 work days
Model :
HDF2-R
Belt Width (mm) :
600
Air Nozzle :
256
Air Pressure (MPa) :
0.6~0.8
Voltage :
220V~ 50/60Hz
Power (kW) :
6.6
Description
HDF-R AI-RGB Sorter AI Powered Precise Color Detection To Non-ferrous Metal Scraps Mix For Recovering Copper, Aluminum And More
Technical Features
  • High-Resolution RGB Camera System

    Precise detection to non-ferrous metals (e.g., copper, aluminum, zinc) according to color, size, shape, thickness and texture differences

  • Proprietary AI Deep Learning Algorithms

    Innovative simulation of manual picking operation by teaching and training the intelligent RGB sorter all the standards and features of identification and sorting

  • High-Intensity LED Illumination System

    Enhanced identification of surface characteristics and features of targeting non-ferrous metal fractions, minimizing false rejects

  • Reliable High-Performance Ejector System

    High-speed and powerful air ejectors designed and produced in-house ensure accurate rejection and reliable performance at high-capacity sorting

  • Versatility and Fast ROI

    One machine handles a variety of scenarios and payback in 6-18 months by non-ferrous metal scraps recovery

Typical Application Scenarios and Benefits
  • Metal Recycling Plants
    : Reduce smelting impurities & energy consumption
    • Extract copper/aluminum from mixed scraps (copper, aluminum, zinc, stainless steel) with efficiency and high purity
  • Auto Dismantlers
    : Improves recovery rates and profitability
    • Extract high-value copper wires from shredder residue to boost profit per ton, distinguishing copper (reddish-brown) from aluminum (silver-white)
  • Battery Recyclers
    : Avoids hydrometallurgy risks
    • Recover high-value electrode by detection to copper (purple-red) and aluminum (silver-white), targeting unpeeled areas
  • E-Waste Processors
    : Boost revenue, cut labor cost and reduce landfill waste
    • Extract gold-plated contacts from discarded mobile phone boards to increase refining profits
  • Appliance Recycling
    : Purely physical sorting, no burning/chemicals
    • Sort copper tubes (reddish-brown) and aluminum heat sinks (silver-white) from refrigerators/AC units
    • Separate copper windings (shiny)from silicon steel (matte) in washing machine motors mix

Non Ferrous Metals Sorter Machines For Recovering Copper , Aluminum

Specifications
Model Belt Width (mm) Air Nozzle Air Pressure (MPa) Air Consumption (m³/min) Voltage Power (kW) Dimension (mm) Unpacked Weight (kg)
HDF2-R 600 256 0.6~0.8 <2.1 220V~ 50/60Hz 6.6 4686×1924×2685 1589
HDF4-R 1200 512 0.6~0.8 <4.1 220V~ 50/60Hz 8.3 5087×2524×2685 2165
HDF6-R 1800 768 0.6~0.8 <4.1 220V~ 50/60Hz 11.8 4998×2963×2685 2419
