Tailored Design Belt Color Sorter 300mm Belt Fruit Grading Machine
Tailored Design Belt Color Sorter 300mm Belt Fruit Grading Machine
Specifications
Brand Name :
PHOENIX
Model Number :
HF AI-RGB Sorter
Place of Origin :
Hefei
MOQ :
1
Price :
Price Negotiable
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Delivery Time :
5-8 work days
Model :
HF1
Belt Width (mm) :
300
Voltage :
220V~50/60Hz
Power (kW) :
3.2
Description
HF AI-RGB Sorter AI Powered And Tailored Design For IQF Vegetables And Fruit Sorting; Engineered For High-pressure Washing And Sterilization
Technical Features
Tailored Sorting Solution for IQF Vegetables and Fruit
  • Compact single-belt sorting system with quick-install design
  • High-capacity waterproof vibratory feeder evenly distributes IQF vegetables and fruit into a single layer to minimize overlapping
  • Reinforced food-grade stainless steel structure and sealed scanning and control boxes withstand frequent high-pressure washing and sterilization
  • Quick belt change ensures convenient routine maintenance and cleaning, meeting higher food safety and hygiene standards
  • Field-proven Humidity Control System integrated maintains consistent performance and minimizes downtime
  • Modular design of belt width from 300 to 1800mm (300/600/1200/1800) provides processors more flexibility
AI Powered 4-in-1 Inspection System
  • Proprietary AI Deep Learning algorithms continuously improves defect recognition based on new samples
  • High-resolution RGB Camera System
  • High-intensity LED Illumination System
  • Market-leading precise detection to a wide range of defects in IQF vegetables and fruit by color, size, shape and texture features:
    • Color Defects: Discoloration, mold, rot
    • Shape Defects: Misshapen, deformed, oversized, undersized, broken
    • Surface Damage: Bruises, cuts, abrasions, crushing, scars, cracks, shriveling
    • Biological Contaminants: Insect damage, leaf/stem residues, other vegetable debris, soil clumps
    • Foreign Materials: Stones, plastic/rubber fragments, wood chips

Tailored Design Belt Color Sorter 300mm Belt Fruit Grading Machine

Technical Parameters
Model Belt Width (mm) Nozzle Quantity Air Supply Pressure (MPa) Air Consumption (L/min) Voltage Power (kW) Main Unit Dimensions (mm) Main Unit Weight (kg)
HF1 300 64 0.6-0.8 <1200 220V~50/60Hz 3.2 3816×1240×1866 672
HF2 600 128 0.6-0.8 <2400 220V~50/60Hz 3.5 4340×1811×2144 882
HF4 1200 256 0.6-0.8 <3600 220V~50/60Hz 4.8 4519×2411×2144 1120
HF6 1800 384 0.6-0.8 <3600 220V~50/60Hz 6.8 4502×3075×2144 1425
