ASTM A351 CF8M 316 Stainless Steel Cap Class 150 Threaded BSPT
ASTM A351 CF8M 316 Stainless Steel Cap Class 150 Threaded BSPT
Specifications
Brand Name :
SMLSCO
Certification :
ISO PED
MOQ :
1pc
Price :
Above 2usd/kg
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability :
100 ton/month
Delivery Time :
3 weeks/container
Packaging Details :
Plywood case
Material :
316
Certificates :
ISO,PED
Brand :
SMLSCO
Price Term :
FOB/CFR/CIF，etc
Payment :
T/T, L/C or as negotiation
Package :
Wooden Box
Description
ASTM A351 CF8M 316 Stainless Steel Cap Class 150 Threaded BSPT

What is Casting Cap?
Casting Cap is a type of pipe fitting with internal threads, used to screw onto the external threads at the end of a pipe or pipe joint to achieve sealing of the pipeline. It provides a safe, reliable, and detachable sealing solution for pipeline terminals. Compared to permanent welded heads, threaded pipe caps allow for greater flexibility in reopening pipelines for maintenance or expansion when needed in the future. Our pipe caps come in various shapes such as hexagonal and circular.
BSPT Threaded Connection
This pipe cap is connected using BSPT (British Standard Pipe Cone Thread). As a cone thread with a tooth profile angle of 55 °, it mainly relies on the interference fit of the thread itself to form a seal during tightening, and is a very effective sealing form in applications such as pipeline sealing. BSPT is a universal thread standard in many regions of Europe and the world, providing a highly compatible and reliable thread solution for various general industrial and plumbing projects.

Product Name: Threaded Cap
Material: Stainless Steel 316 / Casting Grade CF8M
Standard: ASTM A351 (Material) / ISO 4144 (Dimensions, ref.)
Fitting Type: Cap, Casting
Connection: Female Threaded BSPT
Pressure Rating: Class 150
Application: Pipe End Closure, Plumbing, Low-Pressure Systems
Size: Available in various sizes

ASTM A351 CF8M 316 Stainless Steel Cap Class 150 Threaded BSPT


Material Properties of CF8M/316
The use of CF8M/316 stainless steel material provides excellent corrosion resistance protection for the pipeline system. Compared to ordinary 304 material, 316 can more effectively resist the corrosion of chlorides and various industrial chemical media due to the addition of molybdenum element. For low-pressure systems with more complex operating environments or higher requirements for service life, choosing 316 material fittings means choosing lower long-term maintenance costs and higher operational safety.


SMLSCO Manufacturing Process
SMLSCO cast pipe fittings are produced using precision casting (silica sol) technology to achieve excellent dimensional accuracy and surface smoothness. The process first involves making wax molds, wrapping multiple layers of refractory materials on the surface of the wax mold to form a ceramic shell, and then heating the wax mold to melt and flow out. Next, pour the melted stainless steel into the hollow shell. After the molten steel cools and solidifies, the shell can be crushed to obtain high-precision pipe blanks, which are then processed through machining, tapping, and other processes to become the final product.


Why Choose SMLSCO?
Founded in 2006, SMLSCO is a globally leading stockist and solution provider of stainless steel piping systems. We are committed to providing one-stop procurement services, including pipes, flanges, and fittings, to industrial distributors and stockists worldwide. Leveraging our core strengths of "larger inventory, faster delivery, and better prices," SMLSCO has become a reliable partner for you to simplify procurement processes and enhance supply chain efficiency.
