Specifications
Applicable Industries :
Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Farms, Home Use, Construction works , Energy & Mining, Advertising Company
Showroom Location :
Canada, United Kingdom, United States, Germany
Condition :
New
Type :
Gravity Separator, Gravity Separation
Production Capacity :
0.5-1.2 tons per hour
Place of Origin :
Henan, China
Brand Name :
ZHENGZHOU Sinolion
Voltage :
380V/415V/440V( as client request)
Dimension(L*W*H) :
5630*1850*900mm
Weight :
650 KG
Warranty :
1 Year
Marketing Type :
New Product 2023
Machinery Test Report :
Provided
Video outgoing-inspection :
Provided
Warranty of core components :
1 Year
Core Components :
Bearing, Motor, Pump, Gear, Engine, Other
Key Selling Points :
Multifunctional
Application :
gold, chormite, tungsten ore, tin, tantalum ore, niobium mine
Product name :
Shaking Table
After-sales Service Provided :
Service Machinery Overseas
Usage :
Mining Concentration
Name :
Gold Mining Equipment Shaking Table
Color :
Clients' Request
Processed materials :
gold
Capacity :
0.5-1.2 tons per hour
Price :
$1,400.00/sets >=1 sets
MOQ :
1 unit
Description
Product Description
Construction Works Small Portable Gold Mining Equipment Shaker Table for Gold 650 KG

Shaking table for glod

Shaking table is one of the main equipments of gravity beneficiation in the gold processing equipment, mainly used in the separation of tungsten, tin, tantalum, niobium, iron, manganese, chromium, titanium, bismuth, lead, gold and other rare metals and precious metal ores , can also be used in coal mines. It can be used in different operations such as roughing, beneficiation, sweeping, etc., and separate coarse sand (2-0.5mm), fine sand (0.5-0.074mm), ore slime (-0.074) and other different particle sizes. Our compay have two models for gold shaking table, is 6-S and LY. You can select it according to your needs.
Construction Works Small Portable Gold Mining Equipment Shaker Table for Gold 650 KG

Working principle

The mineral processing process of the shaking table is carried out on the inclined bed surface with rebound strips. The ore particles are fed from the ore feed chute, and the horizontal flushing water is supplied from the water supply tank. When the ore particles are under gravity and the force of the transverse flow water, the bed surface is under the action of inertia and friction generated by reciprocating asymmetric motion, the materials are layered according to specific gravity and particle size. Therefore, ore particles with different specific gravity and particle size gradually flow down in a fan shape along their respective directions of movement, and are discharged from different areas on the concentrate end and tailings side respectively, and are finally divided into concentrate, medium ore and tailings.
Product Details
Construction Works Small Portable Gold Mining Equipment Shaker Table for Gold 650 KG
Construction Works Small Portable Gold Mining Equipment Shaker Table for Gold 650 KG
Construction Works Small Portable Gold Mining Equipment Shaker Table for Gold 650 KG
Specification
Specifications
Type 6-S
Type LY
Bed surface size(mm)
4520×1850×1560
2100×1050×850
Length*feed end width*concentrate end ore
Selection area(㎡)
7.671111
2
Feeding particle size(mm)
coarse sand
2-0.5
2-0.5
fine sand
0.5-0.074
0.5-0.074
slime
0.074-0.037
0.074-0.037
Feeding concentration（%）
10～30
10～30
Handling Capacity（t/h）
coarse sand
1-2.5
0.4-0.8
fine sand
0.8-1.2
0.2-0.5
slime
0.3-0.6
0.1-0.2
Water Consumption（t/h）
0.5～3.5
0.2～1
Stroke（mm）
8～36
12～28
Stroke times（times/min）
240～380
250～450
Corss slope（degrees）
0°～5°
0°～10°
Electric Motor
model
Y70L-4
Y90L-4
power（kw）
1.1
1.1
rotating speed（r/min）
1400
1400
V-belt（mm）
A-2000
B-2007
Dimensions(mm) L*W*H
5630×1850×900
3040×1050×1020
Weight（kg）
650
350
Packing & Delivery
Construction Works Small Portable Gold Mining Equipment Shaker Table for Gold 650 KG
Construction Works Small Portable Gold Mining Equipment Shaker Table for Gold 650 KG
Construction Works Small Portable Gold Mining Equipment Shaker Table for Gold 650 KG
Construction Works Small Portable Gold Mining Equipment Shaker Table for Gold 650 KG
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
Certifications
Construction Works Small Portable Gold Mining Equipment Shaker Table for Gold 650 KG
Company Profile
Construction Works Small Portable Gold Mining Equipment Shaker Table for Gold 650 KG
Construction Works Small Portable Gold Mining Equipment Shaker Table for Gold 650 KG
Contact us
Construction Works Small Portable Gold Mining Equipment Shaker Table for Gold 650 KG
Sincerely welcome to send your inquiry, you can get best quotation and professional service!
