Specifications
Applicable Industries :
Home Use, Energy & Mining
Showroom Location :
United States, Italy, Brazil, Mexico, UAE, Colombia, Nigeria, Australia
Condition :
New
Type :
gold mining trommer screen
Production Capacity :
5-350 tons/hour
Place of Origin :
China
Brand Name :
Sinolion
Voltage :
380V/415V/440V
Dimension(L*W*H) :
3000*1000*1800
Weight :
520 KG, 520kg
Warranty :
1 Year
Marketing Type :
New Product 2022
Machinery Test Report :
Provided
Video outgoing-inspection :
Provided
Warranty of core components :
1 Year
Core Components :
Motor, Pump
Key Selling Points :
Automatic
Product name :
gold mining trommel screen
Application :
washing gold
Certification :
CE ISO
Installation :
supply manual to guide user
Color :
yellow, white, red, blue, gray( or as client request)
Capacity :
5-10t/h
Tire diameter :
500mm-650mm
Keywords :
Gold Separation Machine
Function :
Washing Gold Ore
Price :
$4,080.00 - $17,900.00/sets
MOQ :
1 unit
Description
Installation Guide Included Rotary Portable Drum Trommel Screen for Washing Gold Ore
Installation Guide Included Rotary Portable Drum Trommel Screen for Washing Gold Ore
Installation Guide Included Rotary Portable Drum Trommel Screen for Washing Gold Ore
Mobile Stationary Sand Trommel Screen For River Gold Mining Equipment
Our factory can provide trommel screeners for different capacity from 5-350 tons/hour, which meet clients different requirements for operating. We also provide complete sets for capacity from 5-350 tons/hour. When received clients' actual requirements , our engineer will design a flow and make sure all the details. All the products are compact structure, strong integrity, light weight, large handling capacity, simple operation, reliable work, and easy maintenance, easy to move and so on.
Installation Guide Included Rotary Portable Drum Trommel Screen for Washing Gold Ore
Product Name
Model
Capacity (t/h)
Power(kw)
Diameter(mm)
Length(mm)
Gold trommel screen
GMTS0519
5-10
1.5
500
1910
Gold trommel screen
GMTS1020
10-30
4
1000
2000
Gold trommel screen
GMTS1225
30-50
5.5
1200
2500
Gold trommel screen
GMTS1548
80-150
11
1500
4800
Gold trommel screen
GMTS1848
100-200
15
1800
4800
Gold trommel screen
GMTS2060
200-350
30
2000
6000
Installation Guide Included Rotary Portable Drum Trommel Screen for Washing Gold Ore

GMTS 0519

This model is one of our smallest trommel screeners, which have the portable and mobile performance. One adult can pull and move it.The mesh is divided into two parts, one is no-pole rotary drum , the other is manganese wire woven mesh. The pole diameter can be adjusted from 5-8 mm as clients' requirements. The electric motor or diesel generator can be optional in case the lack of electricity.

***Towing hook
***Feeding hopper
***Rotary drum
***Tires
***Water pump
***Motor+reducer+chain
***Sluice box
Installation Guide Included Rotary Portable Drum Trommel Screen for Washing Gold Ore

GMTS1548

This model is one of our hottest selling products. It looks stronger and prettier with high quality and factory price. This is the first choice if the capacity is over 50 tons per hour. The machine is excellent in screening and collecting high efficiently. The mesh pole can be adjusted according to client's requirements.

***Feeding hopper
***Rotary drum
***Tires
***Platform
***Ladder
***Water pump
***Motor+reducer+chain
***Sluice box

Installation Guide Included Rotary Portable Drum Trommel Screen for Washing Gold Ore
Installation Guide Included Rotary Portable Drum Trommel Screen for Washing Gold Ore
Installation Guide Included Rotary Portable Drum Trommel Screen for Washing Gold Ore
Installation Guide Included Rotary Portable Drum Trommel Screen for Washing Gold Ore
Installation Guide Included Rotary Portable Drum Trommel Screen for Washing Gold Ore
Installation Guide Included Rotary Portable Drum Trommel Screen for Washing Gold Ore
Installation Guide Included Rotary Portable Drum Trommel Screen for Washing Gold Ore
Installation Guide Included Rotary Portable Drum Trommel Screen for Washing Gold Ore
Installation Guide Included Rotary Portable Drum Trommel Screen for Washing Gold Ore

Structure and Principle

The Alluvial Gold Trommel Screen Machine Uses The Principle Of Gravity Separation, The Original Ore Through A Layer Of Screening And Classification Under The Impact Of Water Into The Agitation Sluice Chute For Next Step Coarse Separation, If There Is Capillary Gold In The Original Mine, Adding The Agitation Chute Fixed Chute In The Tail To Avoid Tails Running. If There Is Clay Mud In Original Ore, We Will Add Stirring In Front Of The Screen And Flushing Device In Screen Drum, So That The Unfavorable Factors Caused By High Mud Content Can Be Solved Well, And Can Be Adjusted According To Ore Body Condition And Site.
1. Input Of Raw Materials Raw Materials Inputted Through The Entrance Of The Hopper Will Be Pushed Into The Trommel Screen By The Strong Water Pressure Of The Shower Equipped In The Hopper.
2. Selection And Cleaning Of Raw Materials Raw Materials Of The Trommel Screen Will Be Cleaned And Selected By The Rotation Of Trommel Screen And By Watering Of The Shower Inside, Run Into The Gold Dust Separate Panel.
3. Collecting Of Gold Dust Separated Soil And Sands With Lighter Specific Gravity Will Flow Away But Gold Dusts With Greater Specific Gravity Will Be Staying In The Gathering Mat To Be Collected.
