Specifications
Brand Name :
SINOLINK
Model Number :
GS150
Certification :
CE
Place of Origin :
Shandong, China
MOQ :
1 set
Price :
USD+850-950+set
Payment Terms :
T/T
Supply Ability :
300+set+per+month
Delivery Time :
30 days after payment
Packaging Details :
Plywood box 920X760X1100mm
Power :
15hp gasoline engine power
Blades :
2pcs fly blades and 1pcs fixed blade
Wheel :
5.7-8
chipper disc :
20mm thickness
chipper weight :
270kg
Description
disc wood chipper 13.5hp/14Hp /15Hp gas Engine ATV Wood Chipper Shredder cut blades wood branch shredder leaf mulcher
Chip Large Quantities of Wood
The GS150 is capable of chipping and shredding huge quantities of wood and branches into
easily-handled chippings quickly and effortlessly, whether you're using it for domestic or professional purposes.
Up To 12cm Chipping Capacity
Large branches have met their match with this powerful machine! Built to make chipping large branches
simple and easy, the GS150's 2-blade drum mechanism has been designed to draw in and chip branches
and tree trunks with up to a 12cm diameter.

Disc wood chipper Specifications
Model GS150
Start Method Electric or Recoil
Drive Type Belt Drive
Chipping Capacity (mm) 120
Feed Hopper Opening Size (mm) 500x460
Infeed Throat Opening Size (mm) 160x176
Disc Size (mm) (Diameter / Thickness) 550 x 20
Knives 2
Features ATV Towing Bar, 360° Rotating Chute
Handle Type N/A
Safety Features Stop Button
Engine Model Loncin 420FD or B&S XR2100
Engine Type 4 Stroke OHV Single Cylinder
Engine Size (cc) 420
Rated Power (hp) 15
Disc Speed (RPM) 2200
Fuel Petrol
Fuel Capacity (L) 6.5
Engine Oil SAE30
Engine Oil Capacity (ml) 1100
Gross Weight (kg) 270
Tyres 5.7-8
Off Road Tow Bar Yes
Fully Assembled Dimensions (H x W x L) (mm) 2550 x 1010 x 1810
Package Dimensions (H x W x L) (mm) 1250 x 770 x 1050
Fuel Type / Power Source Petrol
Product Type Wood Chipper
Warranty (years) 1
Commercial Warranty (years) 1
In The Box Petrol Wood Chipper, Tool Set, Manual

Petrol Disk Wood Chipper Leaf Mulcher 13.5hp 14Hp 15Hp ATV Small Branch Shredder
There is an Emergency stop Bar at the feeder hopper.

When it is depressed it cuts off the engine.
As the engine reduces speed the clutch will release and the Disc will begin to slow down.
Easy access inside the disc cover to the disc and blades via a quick release latch.

The disc cover has a micro switch to stop the engine being started with the cover open.
The exit shoot, can swivel 360°, throwing the chip into a nearby trailer or pile.

Petrol Disk Wood Chipper Leaf Mulcher 13.5hp 14Hp 15Hp ATV Small Branch Shredder

LONCIN 420cc 27Nm
Easy Pull Start
Double Belt with Clutch (no load during starting)
Capacity 4” 100mm - cutting point is 160Wx 200H (mm)
360° Rotating Discharge Chute
Double Blades (reversible)
Anvil: Adjustable
Large feed shoot, with gravity self feed.
LED tail light and NZ & pin plug
Tyres: E-Mark 5.7-8 Road Tyre
Folding height adjustable jockey wheel
Coupling 1 7/8”
Petrol Disk Wood Chipper Leaf Mulcher 13.5hp 14Hp 15Hp ATV Small Branch Shredder
Extremely strong and robust. Main housing is made of 5mm steel plate, and the base of 4mm plate.

10mm bearing boss plate.
Weight: 260kgs
