Flame Retardent 2:1 Shrink Ratio FEP Heat Shrinkable Tube Clear Plastic Tubing for Insulation and Sheath
Flame Retardent 2:1 Shrink Ratio FEP Heat Shrinkable Tube Clear Plastic Tubing for Insulation and Sheath
Flame Retardent 2:1 Shrink Ratio FEP Heat Shrinkable Tube Clear Plastic Tubing for Insulation and Sheath
Flame Retardent 2:1 Shrink Ratio FEP Heat Shrinkable Tube Clear Plastic Tubing for Insulation and Sheath
Flame Retardent 2:1 Shrink Ratio FEP Heat Shrinkable Tube Clear Plastic Tubing for Insulation and Sheath
Flame Retardent 2:1 Shrink Ratio FEP Heat Shrinkable Tube Clear Plastic Tubing for Insulation and Sheath
Flame Retardent 2:1 Shrink Ratio FEP Heat Shrinkable Tube Clear Plastic Tubing for Insulation and Sheath
Flame Retardent 2:1 Shrink Ratio FEP Heat Shrinkable Tube Clear Plastic Tubing for Insulation and Sheath
Specifications
Brand Name :
Sunbow
Model Number :
SB-FEP-HST
Certification :
ROHS, REACH
Place of Origin :
CHINA
MOQ :
1000M
Price :
USD0.2 TO $2.58/M
Payment Terms :
T/T, Western Union
Supply Ability :
20,000M/DAY
Delivery Time :
5~7 work days
Packaging Details :
spools in cartons
Material :
FEP
Working temperature :
-80~+200 degree C
Shrinkage temperature :
+200 ~+250 degree C
Melting temperature :
260 ~270 degree C
Shrink ratio :
35%
Toughness :
Outstanding
Flame retardant :
VW-1
Tensile strength :
>21MPA
Size :
1.0mm to 30mm
Wall thickness :
0.2mm to 0.4mm
Description

Flame retardent 2:1 Shrink Ratio FEP heat shrinkable tube clear plastic tubing for insulation and sheath

Model Number: SB-FEP-HST
Working temperature:-80 ~ +200 ºC

Shrinkage temperature: +200 ~ +250 ºC

Usage

Mainly used for insulation and sheath, electrical components, wires, cables, under various frequencies;

liquid crystal manufacturing apparatus, the single end emitting single core fiber tube, heat exchanger,

steam piping, high purity reagents conveying pipe, all kinds of corrosive medium conveying pipe.

Flame Retardent 2:1 Shrink Ratio FEP Heat Shrinkable Tube Clear Plastic Tubing for Insulation and Sheath

Specifications

Color

Clear, Black etc

Melting temperature ºC

260--270

Working temperature ºC

-80--200

Shrinkage temperature ºC

200-250

Integrated index

g/10min4-

12

proportion

2.15

Effect of corrosion on copper

No corrosion

Antibacterial property, corrosion resistance

Good

Toughness

Good

Tensile strength Mpa (kgf/cm)

＞21.0

The decomposition temperature ºC

360

Flame retardant

VW-1

Resistance

Abrasion resistance, acid and alkali corrosion, anti dipping, anti fungal, anti corona discharge, industrial solvent, resistance to external mechanical damage

Environmental protection

On the human body and no harm to the environment


Dimension

As supplied ID (mm)After recovery
ID (mm)Wall Thickness (mm)
1.0±0.150.750.2-0.3
1.6±0.21.20.2-0.3
2.4±0.21.60.2-0.3
3.2±0.22.50.2-0.3
4.8±0.23.50.2-0.3
5.72±0.24.50.25-0.3
9.4±0.27.20.25-0.3
10.0±0.28.50.3-0.4
12.7±0.29.50.3-0.4
16.0±0.212.30.3-0.4
18.0±0.213.80.3-0.4
19.0±0.214.60.3-0.4
20.0±0.215.40.3-0.4
22.0±0.2170.3-0.4
25.0±0.319.30.4-0.5
28.0±0.321.60.4-0.5
30.0±0.323.10.4-0.5

Advantages

  1. High working temperature : -80~ 200 degree C
  2. Excellent wear, heat resistance.
  3. Good oil and chemical solvent resistance
  4. Excellent flame retardant
  5. High withstand to abrasion and sut through
  6. Shrink temperature: 200 degree C to 250 degree C
  7. Fast shrinking
  8. Very soft and flexible
  9. Various sizes available, from 1.2mm to 38.1mm
  10. Fast delivery time
  11. Free sample available
  12. Excellent tensile strength
  13. Heat and color resistance 1
  14. Anti-aging
  15. Large application
