Electronic Silicone Gel For Pressure Sensors EV Battery 1:1 Gel Silicone Two-Part Waterproof Potting Compound
Electronic Silicone Gel For Pressure Sensors EV Battery 1:1 Gel Silicone Two-Part Waterproof Potting Compound
Electronic Silicone Gel For Pressure Sensors EV Battery 1:1 Gel Silicone Two-Part Waterproof Potting Compound
Electronic Silicone Gel For Pressure Sensors EV Battery 1:1 Gel Silicone Two-Part Waterproof Potting Compound
Electronic Silicone Gel For Pressure Sensors EV Battery 1:1 Gel Silicone Two-Part Waterproof Potting Compound
Electronic Silicone Gel For Pressure Sensors EV Battery 1:1 Gel Silicone Two-Part Waterproof Potting Compound
Electronic Silicone Gel For Pressure Sensors EV Battery 1:1 Gel Silicone Two-Part Waterproof Potting Compound
Electronic Silicone Gel For Pressure Sensors EV Battery 1:1 Gel Silicone Two-Part Waterproof Potting Compound
Electronic Silicone Gel For Pressure Sensors EV Battery 1:1 Gel Silicone Two-Part Waterproof Potting Compound
Electronic Silicone Gel For Pressure Sensors EV Battery 1:1 Gel Silicone Two-Part Waterproof Potting Compound
Electronic Silicone Gel For Pressure Sensors EV Battery 1:1 Gel Silicone Two-Part Waterproof Potting Compound
Electronic Silicone Gel For Pressure Sensors EV Battery 1:1 Gel Silicone Two-Part Waterproof Potting Compound
Specifications
Keyword :
electrical insulation silicone gel
application :
junction box,pcb,load cell etc
Place of Origin :
Guangdong, China
Packaging Details :
25KG/barrel
Payment Terms :
T/T, D/A, D/P
Color :
Clear
Price :
Negotiable
Type :
ab gel silicone,2 parts
Application :
AC capacitors, negative ion generators, aquarium water pumps, ignition coils
mxi ratio :
1:1
Customzation :
Support
Brand Name :
Hanast
Feature :
electrical insulation，low-viscosity，soft and clear
Model Number :
HN-6607AB
Certification :
ROHS SGS
Name :
Shore 00 Self-Healing Jelly Gel
MOQ :
1kg
Waterproof :
yes
Description

Electronic Silicone Gel For Pressure Sensors EV Battery 1:1 Gel Silicone Two-Part Waterproof Potting Compound

Product Description of softness silicone gel:

Electronic-grade silicone gel is a highly elastic liquid silicone rubber that cures via a cross-linking reaction; upon curing, it transforms into a soft, jelly-like solid and is primarily used to protect sensitive electronic components.

Electronic Silicone Gel For Pressure Sensors EV Battery 1:1 Gel Silicone Two-Part Waterproof Potting Compound

Physical Properties of softness silicone gel:

Characteristics before curing
Component Component A Component B
Color Transparent liquid Transparent liquid
viscosity(cp s. 25℃) 800～2000 800～1800
Relative density(mpa•s) 1 ．0～1.12 0.98～1.02
The mixing ratio A:B=1:1
Viscosity after mixing(cp s. 25℃) 800～1500
Operate Time (25℃) 2 h
Penetration (1/10mm)

~

200 400
Curing conditions (120℃) 20~30 分钟

Cured properties

Hardness(Shore A, 24hr)

 0～10

Advatanges of softness silicon gel :

1. Low viscosity, good flowability, bubble-free
2. Appearance: Transparent, high clarity
3. Temperature resistance: Withstands high and low temperatures
4. Waterproof (IP68 rating)
5. High shock resistance, low stress, impact resistant
6. Flame retardant
7. Yellowing-resistant, UV-resistant
8. Adjustable viscosity and curing time
9. Compatible with automated dispensing equipment
10. High flexibility; soft and jelly-like after curing
11. Fillers can be added (e.g., pigments, thermally conductive powder, flame retardants)

Electronic Silicone Gel For Pressure Sensors EV Battery 1:1 Gel Silicone Two-Part Waterproof Potting Compound

Physical Properties of softness silicone gel

Characteristics before curing
Component
Component A
Component B
Color
Transparent liquid
Transparent liquid
viscosity(cp s. 25℃)
800～2000
800～1800
Relative density(mpa•s)
1 ．0～1.12
0.98～1.02
The mixing ratio
A:B=1:1
Viscosity after mixing(cp s. 25℃)
800～1500
Operate Time (25℃)
2 h
Penetration (1/10mm)
200~ 400
Curing conditions (120℃)
20~30 mins
Cured properties
Hardness(Shore A, 24hr)
0～10

Electronic Silicone Gel For Pressure Sensors EV Battery 1:1 Gel Silicone Two-Part Waterproof Potting Compound

Applications of our silicone gel :

Electronic Silicone Gel For Pressure Sensors EV Battery 1:1 Gel Silicone Two-Part Waterproof Potting Compound

Electronic Silicone Gel For Pressure Sensors EV Battery 1:1 Gel Silicone Two-Part Waterproof Potting Compound
