Transparent Silicone Potting Gel Pcb Waterproofing 1:1 Jelly Gel For Load Cell Waterproof Scale
Transparent Silicone Potting Gel Pcb Waterproofing 1:1 Jelly Gel For Load Cell Waterproof Scale
Transparent Silicone Potting Gel Pcb Waterproofing 1:1 Jelly Gel For Load Cell Waterproof Scale
Transparent Silicone Potting Gel Pcb Waterproofing 1:1 Jelly Gel For Load Cell Waterproof Scale
Transparent Silicone Potting Gel Pcb Waterproofing 1:1 Jelly Gel For Load Cell Waterproof Scale
Transparent Silicone Potting Gel Pcb Waterproofing 1:1 Jelly Gel For Load Cell Waterproof Scale
Transparent Silicone Potting Gel Pcb Waterproofing 1:1 Jelly Gel For Load Cell Waterproof Scale
Transparent Silicone Potting Gel Pcb Waterproofing 1:1 Jelly Gel For Load Cell Waterproof Scale
Transparent Silicone Potting Gel Pcb Waterproofing 1:1 Jelly Gel For Load Cell Waterproof Scale
Transparent Silicone Potting Gel Pcb Waterproofing 1:1 Jelly Gel For Load Cell Waterproof Scale
Transparent Silicone Potting Gel Pcb Waterproofing 1:1 Jelly Gel For Load Cell Waterproof Scale
Transparent Silicone Potting Gel Pcb Waterproofing 1:1 Jelly Gel For Load Cell Waterproof Scale
Specifications
Name :
Shore 00 Self-Healing Jelly Gel
Certification :
ROHS SGS
Feature :
electrical insulation，low-viscosity，soft and clear
application :
junction box,pcb,load cell etc
Packaging Details :
25KG/barrel
Application :
AC capacitors, negative ion generators, aquarium water pumps, ignition coils
mxi ratio :
1:1
Brand Name :
Hanast
Payment Terms :
T/T, D/A, D/P
Model Number :
HN-6607AB
Type :
ab gel silicone,2 parts
Waterproof :
yes
Color :
Clear
Place of Origin :
Guangdong, China
Keyword :
electrical insulation silicone gel
Customzation :
Support
Price :
Negotiable
MOQ :
1kg
Description

Transparent silicone potting gel pcb waterproofing 1:1 jelly gel for load cell waterproof scale

Product Description of softness silicone gel:

The 1:1 silicone gel is a very soft, semi-solid material used for encapsulating electronics. It's made by mixing two parts (A and B) in equal amounts by volume or weight, and it cures through addition polymerization.

Transparent Silicone Potting Gel Pcb Waterproofing 1:1 Jelly Gel For Load Cell Waterproof Scale

Physical Properties of softness silicone gel:

Characteristics before curing
Component Component A Component B
Color Transparent liquid Transparent liquid
viscosity(cp s. 25℃) 800～2000 800～1800
Relative density(mpa•s) 1 ．0～1.12 0.98～1.02
The mixing ratio A:B=1:1
Viscosity after mixing(cp s. 25℃) 800～1500
Operate Time (25℃) 2 h
Penetration (1/10mm)

~

200 400
Curing conditions (120℃) 20~30 分钟

Cured properties

Hardness(Shore A, 24hr)

 0～10

Advatanges of softness silicon gel :

Extremely low hardness ("jelly-like"): Unlike standard silicone rubber, 1:1 silicone gels do not become rigid after curing; their hardness is typically not measured using the standard Shore A scale but is instead expressed in terms of penetration (e.g., 30–100 × 0.1 mm). They exhibit a consistency resembling jelly, gel, or "sticky gummy candy." Self-adhesion and self-healing: They possess inherent surface tackiness, allowing them to adhere automatically to the vast majority of substrates. If the gel is pierced by a needle, it automatically heals and restores itself after the needle is withdrawn, maintaining its sealing and waterproofing integrity. Exceptional transparency: The vast majority of 1:1 silicone gels are colorless and transparent after curing, facilitating the visual inspection of internal components.

Transparent Silicone Potting Gel Pcb Waterproofing 1:1 Jelly Gel For Load Cell Waterproof Scale

Physical Properties of softness silicone gel

Characteristics before curing
Component
Component A
Component B
Color
Transparent liquid
Transparent liquid
viscosity(cp s. 25℃)
800～2000
800～1800
Relative density(mpa•s)
1 ．0～1.12
0.98～1.02
The mixing ratio
A:B=1:1
Viscosity after mixing(cp s. 25℃)
800～1500
Operate Time (25℃)
2 h
Penetration (1/10mm)
200~ 400
Curing conditions (120℃)
20~30 mins
Cured properties
Hardness(Shore A, 24hr)
0～10

Transparent Silicone Potting Gel Pcb Waterproofing 1:1 Jelly Gel For Load Cell Waterproof Scale

Applications of our silicone gel :

Transparent Silicone Potting Gel Pcb Waterproofing 1:1 Jelly Gel For Load Cell Waterproof Scale

Send your message to this supplier
Send Now

Transparent Silicone Potting Gel Pcb Waterproofing 1:1 Jelly Gel For Load Cell Waterproof Scale

Ask Latest Price
Watch Video
Product Detail
Name :
Shore 00 Self-Healing Jelly Gel
Certification :
ROHS SGS
Feature :
electrical insulation，low-viscosity，soft and clear
application :
junction box,pcb,load cell etc
Packaging Details :
25KG/barrel
Application :
AC capacitors, negative ion generators, aquarium water pumps, ignition coils
