3000W Rated Power Solar Hybrid Inverter with Pure Sine Wave and Multi-Function for 50Hz/60Hz Applications
3000W Rated Power Solar Hybrid Inverter with Pure Sine Wave and Multi-Function for 50Hz/60Hz Applications
3000W Rated Power Solar Hybrid Inverter with Pure Sine Wave and Multi-Function for 50Hz/60Hz Applications
3000W Rated Power Solar Hybrid Inverter with Pure Sine Wave and Multi-Function for 50Hz/60Hz Applications
3000W Rated Power Solar Hybrid Inverter with Pure Sine Wave and Multi-Function for 50Hz/60Hz Applications
3000W Rated Power Solar Hybrid Inverter with Pure Sine Wave and Multi-Function for 50Hz/60Hz Applications
3000W Rated Power Solar Hybrid Inverter with Pure Sine Wave and Multi-Function for 50Hz/60Hz Applications
3000W Rated Power Solar Hybrid Inverter with Pure Sine Wave and Multi-Function for 50Hz/60Hz Applications
Specifications
Certification :
CE,ROSH,FCC
Place of Origin :
China
MOQ :
200set
Payment Terms :
T/T
Supply Ability :
10000 set/month
Delivery Time :
30-35days
Packaging Details :
Carton/Wooden crate
Rated Power :
3000 W
Input Voltage :
24 Vdc
Input Voltage Range :
19–30 Vdc
Low Voltage Alarm :
20 Vdc
Low Voltage Protection :
19 Vdc, Inverter Output Shutdown
Low Voltage Recovery :
22 Vdc
Overvoltage Protection :
32 Vdc, Inverter Output Shutdown
Mains Charging Power :
750W
Output Waveform :
Pure Sine Wave
Description
3000W Rated Power Solar Hybrid Inverter, Pure Sine Wave, Multi-Function, 50Hz/60Hz
Technical Specifications
Input Voltage 24 Vdc
Input Voltage Range 19-30 Vdc
Low Voltage Alarm 20 Vdc
Low Voltage Protection 19 Vdc, Inverter Output Shutdown
Low Voltage Recovery 22 Vdc
Overvoltage Protection 32 Vdc, Inverter Output Shutdown
Rated Power 3000 W
AC Voltage 220 V
Output Frequency 50Hz/60Hz
No-load Current ≤0.8A
Conversion Efficiency ≤91%
Output Waveform Pure Sine Wave
Total Harmonic Distortion (THD) <3% (Linear Load)
Overload Protection ≥3500W, Inverter Output Shutdown
Standby Power Consumption 22W
Rated Voltage 220V
Rated Frequency 50Hz/60Hz
Mains Charging Power 750W
Maximum Efficiency ≤91%
UPS Mains Switching Time <20 ms
Ports & Connections
MPPT Charging Port 1 (Model: XT90)
Mains Charging Port 1 (Tri-pin plug)
Data Communication Port 1 (RS-485)
Positive/Negative Terminal Connections Screw-tightened
Cooling Fans 2 (Intelligent control)
Operating Characteristics
Over-temperature Protection ≥85°C, inverter output shuts down
Operating Modes Inverter mode; Rectifier mode (mains charging, MPPT); UPS
Operating Environment -20 to 60°C; 10 to 90% RH (non-condensing)
Storage Environment -40 to 70°C; 10 to 95% RH (non-condensing)
Operating Altitude ≤3000 m (Derated operation above 1000 m)
Physical Dimensions
Product Dimensions 471 * 318 * 115 mm (L * W * H)
Product Weight (Net Weight) 6.65 kg
Packaging Dimensions 520 * 375 * 175 mm (L * W * H)
Packaging Weight (Gross Weight) 7.8 kg
