Specifications
Certification :
CE,ROSH,FCC
Place of Origin :
China
MOQ :
200set
Payment Terms :
T/T
Supply Ability :
10000 set/month
Delivery Time :
30-35days
Packaging Details :
Carton/Wooden crate
Rated Power :
5000 W
Description
5000W Hybrid Inverter with Pure Sine Wave and Multi-Function Protection
Product Overview

High-quality portable solar inverter featuring pure sine wave output and comprehensive protection systems for reliable power conversion in various applications.

Technical Specifications
Input Voltage 48 Vdc
Input Voltage Range 39-60 Vdc
Rated Power 5000 W
AC Voltage 220 V
Output Frequency 50Hz/60Hz
Output Waveform Pure Sine Wave
Conversion Efficiency ≤93%
Total Harmonic Distortion <3% (Linear Load)
Mains Charging Power 1200W
UPS Switching Time <20 ms
Protection Features
  • Low Voltage Protection: 39 Vdc (Inverter Output Shutdown)
  • Low Voltage Recovery: 46 Vdc
  • Overvoltage Protection: 61 Vdc (Inverter Output Shutdown)
  • Overload Protection: ≥5500W (Inverter Output Shutdown)
  • Over-Temperature Protection: ≥85°C (shuts down inverter output)
Connectivity & Ports
  • AC Output Sockets: 2
  • USB Ports: 4 (2 USB-A, 2 USB-C)
  • AC Output Terminal Block: 1
  • MPPT Charging Port: 1 (XT90 connector)
  • Mains Charging Port: 1
  • Data Communication Port: 1 (RS-485)
Physical Specifications
Product Dimensions 296 × 318 × 104 mm (L × W × H)
Product Weight (Net) 7.45 kg
Packaging Dimensions 375 × 345 × 170 mm (L × W × H)
Packaging Weight (Gross) 9.7 kg
Operating Conditions
  • Operating Temperature: -20°C to 60°C
  • Storage Temperature: -40°C to 70°C
  • Humidity: 10-90% RH (non-condensing)
  • Operating Altitude: ≤3000 m (derated above 1000 m)
