1500W Pure Sine Wave Solar System Inverter with Advanced Diagnostic Features and Real-Time Tracking
1500W Pure Sine Wave Solar System Inverter with Advanced Diagnostic Features and Real-Time Tracking
1500W Pure Sine Wave Solar System Inverter with Advanced Diagnostic Features and Real-Time Tracking
1500W Pure Sine Wave Solar System Inverter with Advanced Diagnostic Features and Real-Time Tracking
1500W Pure Sine Wave Solar System Inverter with Advanced Diagnostic Features and Real-Time Tracking
1500W Pure Sine Wave Solar System Inverter with Advanced Diagnostic Features and Real-Time Tracking
1500W Pure Sine Wave Solar System Inverter with Advanced Diagnostic Features and Real-Time Tracking
1500W Pure Sine Wave Solar System Inverter with Advanced Diagnostic Features and Real-Time Tracking
Specifications
MOQ :
200set
Payment Terms :
T/T
Supply Ability :
10000 set/month
Delivery Time :
30-35days
Packaging Details :
Carton/Wooden crate
Rated power :
1500W
Description
1500W User Friendly Solar System Inverter
Product Overview

Advanced solar power inverter featuring comprehensive diagnostic capabilities and real-time performance monitoring for optimal solar system operation.

Technical Specifications
Rated Power 1500W
Input Voltage 24 Vdc (Range: 19-30 Vdc)
AC Output 220V, 50Hz/60Hz, Pure Sine Wave
Conversion Efficiency ≤91%
Total Harmonic Distortion <3% (Linear Load)
No-Load Current ≤0.8A
Standby Power Consumption 22W
Protection Features
  • Low Voltage Protection: 19 Vdc (Shutdown)
  • Low Voltage Alarm: 20 Vdc
  • Low Voltage Recovery: 22 Vdc
  • Overvoltage Protection: 32 Vdc (Shutdown)
  • Overload Protection: ≥2000W (Shutdown)
  • Short-Circuit Protection
  • Over-Temperature Protection: ≥85°C (Shutdown)
Connectivity & Ports
  • AC Output Sockets: 2
  • USB Ports: 4 (2 USB-A, 2 USB-C)
  • MPPT Charging Port: 1 (XT90 connector)
  • Mains Charging Port: 1 (3-pin plug, 500W)
  • Data Communication Port: 1 (RS-485)
  • LCD Display for comprehensive system monitoring
Operating Characteristics
Operating Modes Inverter Mode; Rectifier Mode (Mains Charging, MPPT); UPS
UPS Switching Time <20ms
Operating Temperature -20°C to 60°C
Operating Humidity 10-90% RH (Non-condensing)
Operating Altitude ≤3000 m (Derated above 1000 m)
Physical Specifications
Product Dimensions 296 * 318 * 104 mm (L * W * H)
Product Weight (Net) 4.8 kg
Packaging Dimensions 375 * 345 * 170 mm (L * W * H)
Packaging Weight (Gross) 6 kg
