Pneumatic Pipe Plug Variable-diameter Bypass Plugging Airbag
Pneumatic Pipe Plug Variable-diameter Bypass Plugging Airbag
Pneumatic Pipe Plug Variable-diameter Bypass Plugging Airbag
Pneumatic Pipe Plug Variable-diameter Bypass Plugging Airbag
Pneumatic Pipe Plug Variable-diameter Bypass Plugging Airbag
Pneumatic Pipe Plug Variable-diameter Bypass Plugging Airbag
Pneumatic Pipe Plug Variable-diameter Bypass Plugging Airbag
Pneumatic Pipe Plug Variable-diameter Bypass Plugging Airbag
Pneumatic Pipe Plug Variable-diameter Bypass Plugging Airbag
Pneumatic Pipe Plug Variable-diameter Bypass Plugging Airbag
Pneumatic Pipe Plug Variable-diameter Bypass Plugging Airbag
Pneumatic Pipe Plug Variable-diameter Bypass Plugging Airbag
Specifications
Model Number :
Pipe plug
Warranty :
2 Years
MOQ :
1pc
Delivery Time :
2~3 weeks
Water Depth :
0~10m, or customzied
Payment Terms :
T/T
Diameter :
0.3~2.5m, or customized diameter
Accessories :
Swivel, pressure gauge, quick connector, adaptor
Working Pressure :
0.1~0.25Mpa
Certification :
SGS, BV, CCS, ABS, LR, BV.
Price :
$USD 120 - 790
Length :
0.8m-4.8m, or customized length
Supply Ability :
100pcs/per week
Name :
Inflatable Pipe Plugs High Pressure Airbags with Full Accessories
Place of Origin :
China
Packaging Details :
papper/woden boxes, Pallet
Brand Name :
DOOWIN MARINE
Certificate :
BV/ABS/LR/CCS ,ect.
Description
DOOWIN Large Diameter Inflatable Pipe Plugs High Pressure Airbags with Full Accessories
Commercial series inflatable pipe plugs are constructed with high-quality natural rubber, NBR, neoprene rubber, or other durable materials, reinforced with nylon layers for enhanced resistance to fuel, petrochemicals, and other caustic chemicals. Each plug comes equipped with rigging hardware, inflation ports, and a pressure relief valve.
Pneumatic Pipe Plug Variable-diameter Bypass Plugging Airbag
These multi-size flow stoppers can accommodate a range of pipe diameters, making them versatile for various applications. Their lightweight design ensures easy installation and quick removal, ideal for commercial and light industrial work. When inflated with air or inert gas, they expand to completely block pipes for maintenance, construction, or other projects.
Pneumatic Pipe Plug Variable-diameter Bypass Plugging Airbag
Specification of Pipe Plug
Model Pipe Diameter (mm) Air Pressure (MPA) Diameter (mm) Length (mm) Weight (kg)
DN150-300 150-300 0.2 135 500 2.5
DN200-400 200-400 0.2 180 600 4
DN200-500 200-500 0.2 180 750 5
DN300-600 300-600 0.15 280 750 10
DN400-800 400-800 0.15 380 900 18
DN500-1000 500-1000 0.15 460 1050 25
Inflatable Pipe Plugs Features
Doowin Marine uses the most durable materials and rigorous testing to ensure the safety and longevity of our plugs. Our inflatable pipe plugs offer these key features and benefits:
Municipal Series Blocking Pipe Plugs are Lightweight and Durable
  • Suitable for commercial, municipal, large diameter, or high-pressure pipes and pipe systems
  • Constructed with high-quality rubber and synthetic-tire-cord for lightweight toughness
  • Flexible design simplifies installations in difficult-to-access locations
  • Reinforced with synthetic-tire-cord for extra durability
  • Tested at higher pressures than working pressure for safety assurance
  • Sturdy products designed for tough jobs in demanding environments
  • Complete set of accessories included for immediate use
  • Adaptable to almost any pipe configuration
  • Compact deflated size enables fast, easy, and safe insertion and operation
Pneumatic Pipe Plug Variable-diameter Bypass Plugging Airbag

Pneumatic Pipe Plug Variable-diameter Bypass Plugging Airbag

Pneumatic Pipe Plug Variable-diameter Bypass Plugging Airbag

Pneumatic Pipe Plug Variable-diameter Bypass Plugging Airbag
