JK850 Geothermal Drilling Rig 850m Depth 600mm Diameter Rotary Table Borehole Machine Heat Exchange
JK850 Geothermal Drilling Rig 850m Depth 600mm Diameter Rotary Table Borehole Machine Heat Exchange
JK850 Geothermal Drilling Rig 850m Depth 600mm Diameter Rotary Table Borehole Machine Heat Exchange
JK850 Geothermal Drilling Rig 850m Depth 600mm Diameter Rotary Table Borehole Machine Heat Exchange
JK850 Geothermal Drilling Rig 850m Depth 600mm Diameter Rotary Table Borehole Machine Heat Exchange
JK850 Geothermal Drilling Rig 850m Depth 600mm Diameter Rotary Table Borehole Machine Heat Exchange
Specifications
Base Type :
Skid-mounted (Crawler track optional)
Certification :
ISO 9001:2015, CE
Packaging Details :
Nude packing in container, key components secured with steel wire and wooden bracing
Drilling Depth :
850m
Auxiliary Hoist Lifting Capacity :
50KN
Mud Pump Flow Rate :
850 L/min
MOQ :
1 Set
Rotary Table Torque :
34KN.m
Mast Effective Height :
47m
Main Hoist Lifting Capacity :
80KN
Drill Pipe Diameter Options :
89mm, 141mm Square, 219mm, 245mm, 273mm, 325mm
Machine Weight :
35,000 kg
Rotary Table Speed :
40, 80, 160, 320 r/min forward and reverse
Drill Pipe Length :
3m / 6m
Price :
Negotiable
Payment Terms :
T/T,L/C
Drilling Diameter Range :
105-600mm
Model Number :
JK850
Supply Ability :
5 Sets per Month
Brand Name :
JK
Feeding Stroke :
4.5m
Place of Origin :
China
Power Source :
Electric Motor Y315S-4 110KW / Diesel Engine 1513BZLD
Rotary Table Through Hole :
850mm
Description

JK850 Geothermal Drilling Rig

Geothermal boreholes put two demands on a rig: depth and torque. The JK850 covers both. It is rated to 850 meters, which is deep enough for closed-loop heat exchange fields and for many production-scale geothermal projects. And with 34KN.m of rotary table torque, it keeps turning in the hard, abrasive formations that geothermal work usually hits.

Most of our geothermal customers run the electric motor version because drilling sites near buildings or urban areas often have power available, and the lower noise is a real advantage when work continues near residences. For remote sites, the 1513BZLD diesel version works just as well.

What makes it suited to geothermal work

  • 850m rated depth for deep heat exchange loops and exploration boreholes
  • High torque at low rotary speeds for hard rock and fractured formations
  • 850 L/min mud pump for effective hole cleaning in abrasive cuttings
  • 47m mast and 6m drill pipe handling for fast tripping between runs

Straight holes matter

Geothermal loop installation depends on hole straightness, and the JK850's rigid mast and 4.5m feed stroke help keep the hole on line. The four-speed table lets the driller keep rotation moderate in broken ground, where aggressive speed tends to walk the bit off course.

The rig accepts standard drill pipe (219, 245, 273, 325mm round, or 141mm square / 89mm hex kelly) and 3m or 6m sections, so you can match the string to your project without special tooling.

Send us your planned loop depth, hole diameter, and the ground conditions from nearby wells. We will recommend the configuration, confirm spares for the starter kit, and give you a complete quote with shipping.
