Jinke JK930 Truck Mounted Water Well Drilling Rig 300m Depth 6X4 Chassis Air DTH Hammer Mud Rotary
Jinke JK930 Truck Mounted Water Well Drilling Rig 300m Depth 6X4 Chassis Air DTH Hammer Mud Rotary
Jinke JK930 Truck Mounted Water Well Drilling Rig 300m Depth 6X4 Chassis Air DTH Hammer Mud Rotary
Jinke JK930 Truck Mounted Water Well Drilling Rig 300m Depth 6X4 Chassis Air DTH Hammer Mud Rotary
Jinke JK930 Truck Mounted Water Well Drilling Rig 300m Depth 6X4 Chassis Air DTH Hammer Mud Rotary
Jinke JK930 Truck Mounted Water Well Drilling Rig 300m Depth 6X4 Chassis Air DTH Hammer Mud Rotary
Jinke JK930 Truck Mounted Water Well Drilling Rig 300m Depth 6X4 Chassis Air DTH Hammer Mud Rotary
Jinke JK930 Truck Mounted Water Well Drilling Rig 300m Depth 6X4 Chassis Air DTH Hammer Mud Rotary
Jinke JK930 Truck Mounted Water Well Drilling Rig 300m Depth 6X4 Chassis Air DTH Hammer Mud Rotary
Jinke JK930 Truck Mounted Water Well Drilling Rig 300m Depth 6X4 Chassis Air DTH Hammer Mud Rotary
Specifications
Engine Power :
290-340HP Diesel
Working Air Pressure :
1.05-2.5 MPa
Model Number :
JK930
Supply Ability :
20 Units per Month
Rotation Torque :
8000-10000 N·m
Lifting Force :
25 Tons
Air Compressor Type :
Screw Type High Pressure
Rotation Speed :
0-80 rpm
Delivery Time :
35-55days
Air Consumption :
17-35 m³/min
Drilling Method :
Air DTH / Mud Rotary
Max Drilling Depth :
300 Meters
Place of Origin :
Henan, China
Packaging Details :
Nude packing on flat rack container or RORO vessel, anti-rust coating on exposed metal, cabin and control panel shrink-wrapped, tools and accessories in export-grade plywood case
Payment Terms :
T/T,L/C
Brand Name :
Jinke
Chassis Type :
6X4 Heavy Duty Truck
Feed Stroke :
3.5 Meters
Hole Diameter Range :
105-350mm
Certification :
ISO 9001:2015, CE
MOQ :
1 Unit
Price :
Negotiable
Description

Jinke JK930 Truck Mounted Water Well Drilling Rig - 300m

Product Overview

The JK930 is Jinke's proven 300-meter class truck mounted water well drilling rig, built on a 6X4 heavy truck chassis. It combines a high-pressure screw compressor for DTH air hammer drilling with a mud pump system for rotary drilling — giving operators the flexibility to switch methods based on formation conditions without changing equipment.

The hydraulic system features independent oil cooling, keeping temperatures stable even in 45°C+ ambient conditions. The feed system uses a cylinder-chain dual-action mechanism delivering 25 tons of pullback force — critical for freeing stuck drill strings in fractured formations.
