Computer Controlled DC Motor Test System Motor Comprehensive Test Bench
Computer Controlled DC Motor Test System Motor Comprehensive Test Bench
Computer Controlled DC Motor Test System Motor Comprehensive Test Bench
Computer Controlled DC Motor Test System Motor Comprehensive Test Bench
Computer Controlled DC Motor Test System Motor Comprehensive Test Bench
Computer Controlled DC Motor Test System Motor Comprehensive Test Bench
Specifications
Brand Name :
Sansion
Certification :
CE SGS ISO9001
Place of Origin :
Chnia
MOQ :
1
Price :
US $1,000-50,000 /
Payment Terms :
TT LC
Packaging Details :
plywood case
Model NO. :
SXDJ
Max Diameter of Workpiece :
2000mm
Mass Scope of Workpiece :
1000kg
Type :
Strength Testing Machine
Maxcapacity :
<1000KN
Accuracy Grade :
0.5
Load Way :
Electronic Load
Loading Method :
Dynamic Load
Display :
Digital
Control :
Manual/Auto at Customized
Weight :
500-1000Kg
Power Source :
AC380V
Oil Cylinder Position :
Under
Test Project1 :
Hv/LV Motor Turn to Turn Withstand Voltage Test
Test Project2 :
Hv/LV Motors Measurement of No-Load Loss
Test Project3 :
Hv/LV Motors Measurement of No-Load Current
Test Project4 :
Hv/LV Motors Cold Resistance Test
Test Project5 :
Three/Single Phase Voltage/ Average Voltage Test
Test Project6 :
Vibration Measurement
Test Project7 :
Temperature Measurement
Test Project8 :
Insulation Resistance Measurement
Test Project9 :
Power Frequency Withstand Voltage Test
Test Project10 :
Three/Single Phase Current/Average Current Test
Test Project11 :
Torque and Speed Measurement
Test Project12 :
Temperature Rise Test
Test Project13 :
Load Test
Test Project14 :
Blockage Test
Transport Package :
Plywood Case
Specification :
1000mm*600mm*560mm
Trademark :
Sansion
Origin :
China
HS Code :
9030339000
Production Capacity :
100 Units/Month
Description

Automated DC Motor Comprehensive Test Bench

General Information:
The SXDJ DC Motor Comprehensive Test Bench is a special system equipment independently developed by our company,
which can be widely used in the factory test system of various motors, and can also be extended to the motor type test system.
Designed and manufactured using advanced computer-controlled measurement technology, it has the characteristics of greatly reduced installed capacity,
advanced technology, reliable operation, strong functions, high precision, good repeatability, energy saving and consumption reduction, advanced, economical, and cost-effective.
The system adopts industrial computer control and integrates the measurement of resistance, insulation, withstand voltage, turn-to-turn, no-load and other items.
It has the advantages of fast test speed, high accuracy, convenient use, and good reliability. It is a comprehensive test equipment dedicated to the motor factory.
Main technical data table:
-Measurement of winding resistance
-Measurement of voltage ratio
-Checking of phase displacement
-Measurement of short-circuit impedance and load loss
-Measurement of no-load loss and current
-Dielectric routine tests (please check below according to the Um (IEC 60076-3))
-Insulation test and functional verification of accessories
-Tests on on-load tap changers, where appropriate
-Auxiliary wiring insulation test
-Check of the ratio and polarity of built-in transformers
-Temperature-rise type test (IEC 60076-2)
-Measurement of no-load loss and current at 90% and 110% of rated voltage
-Low voltage motor AC applied withstand voltage testing
-Low voltage motor turn-to turn insulation testing
-Low voltage three phase voltage, current balance testing
-Bearing vibration testing
-Cold Resistance
-Low Starting Current
-Locked-rotor Current
