Specifications
Brand Name :
RUYA
Model Number :
2ST580-AH
Certification :
ISO 9001
Place of Origin :
China
MOQ :
1 set
Price :
negotiable
Payment Terms :
T/T
Supply Ability :
≤3 sets， 3 months
Delivery Time :
3-4 months
Packaging Details :
wooden box
Load Weight :
40Kg
Rotary Accuracy :
±3″
Perpendicularity :
±3″
Positioning Repeatability :
±2″
Display Resolution :
0.0001°
Lift Range :
200mm
Angle Rotary Range( inner frame) :
continuous rotation
Angle Rotary Range( outer frame) :
±90°
Description
2ST580-AH Dual Axis Manual Digital Display Position Turntable With Lifting
Product Overview

The 2ST580-AH dual-axis manual digital display position turntable with lift is designed for static attitude simulation of the two degrees of freedom of the inner and outer rings of test pieces, either individually or simultaneously. This precision instrument is also suitable for detecting angle output accuracy and calibration of test piece components.

  • Manual operation with fine adjustment capabilities
  • Dual-axis positioning with locking devices
  • Digital display for precise measurement
  • Integrated lifting mechanism
Technical Specifications
Specification Value
Load Weight 40Kg
Table Diameter Ф580mm
Table Flatness 0.02mm
Table Runout 0.02mm
Rotary Accuracy Of Dual-Axis ±3″
Perpendicularity Of Dual-Axis ±3″
Intersection Of Dual-Axis Ф0.5mm diameter ball
Positioning Error Of Angular Position Outer frame: ±5″
Inner frame: ±5″
Positioning Repeatability Of Angular Position ±2″
Angle Rotary Range Inner frame: Continuous rotation
Outer frame: ±90°
Display Mode Degree: 0.0000-359.9999°
Degrees, minutes and seconds: 0°0′0″-359°59′59″
Radian: 0.0000-6.2832
Display Resolution 0.0001°
Lift Range 200mm
Product Images
2ST580-AH Dual Axis Manual Turntable with 200mm Lift Range for Precise Positioning 2ST580-AH Dual Axis Manual Turntable with 200mm Lift Range for Precise Positioning
