2DT450-A04 Dual-axis Electric Turntable with 20Kg Load Weight 450mm Table Diameter and for Inertial Navigation Testing
2DT450-A04 Dual-axis Electric Turntable with 20Kg Load Weight 450mm Table Diameter and for Inertial Navigation Testing
2DT450-A04 Dual-axis Electric Turntable with 20Kg Load Weight 450mm Table Diameter and for Inertial Navigation Testing
2DT450-A04 Dual-axis Electric Turntable with 20Kg Load Weight 450mm Table Diameter and for Inertial Navigation Testing
2DT450-A04 Dual-axis Electric Turntable with 20Kg Load Weight 450mm Table Diameter and for Inertial Navigation Testing
2DT450-A04 Dual-axis Electric Turntable with 20Kg Load Weight 450mm Table Diameter and for Inertial Navigation Testing
2DT450-A04 Dual-axis Electric Turntable with 20Kg Load Weight 450mm Table Diameter and for Inertial Navigation Testing
2DT450-A04 Dual-axis Electric Turntable with 20Kg Load Weight 450mm Table Diameter and for Inertial Navigation Testing
Specifications
Brand Name :
RUYA
Certification :
ISO 9001
Place of Origin :
China
MOQ :
1 set
Price :
negotiable
Payment Terms :
T/T
Supply Ability :
≤3 sets， 3 months
Delivery Time :
3 months
Packaging Details :
wooden box
Load Weight :
20Kg
Table Diameter :
Ф450mm
Positioning Error Of Angular Position(outer frame) :
±2″
Positioning Error Of Angular Position(inner frame) :
±2″
Rate Range(inner frame) :
0.01°/s~1000°/s
Rate Range(outer frame) :
0.01°/s~500°/s
User Slip Ring :
Customizable
Weight :
≤200Kg
Description
2DT450-A04 Dual-axis Electric Turntable Inertial Navigation Test Rate Position Table
Product Overview

The dual-axis electric turntable features two degrees of motion freedom in azimuth axis (X) and pitch axis (Y). This tabletop two-dimensional precision testing equipment is primarily used for testing and calibration of position, rate, swing, and other functions of inertial devices and components.

Technical Specifications
Specification Details
Load Weight 20Kg
Table Diameter Ф450mm
Table Flatness 0.02mm
Table Runout 0.02mm
Rotary Accuracy Of Dual-Axis ±2″
Perpendicularity Of Dual-Axis ±2″
Intersection Of Dual-Axis Ф0.5mm diameter ball
Positioning Error Of Angular Position Outer frame: ±2″
Inner frame: ±2″
Positioning Repeatability Of Angular Position ±2″
Rate Range Inner frame: 0.01°/s ~ 1000°/s
Outer frame: 0.01°/s ~ 500°/s
Rate Accuracy ω ≤ 1°/s: 2*10⁻³ (1° average)
1°/s ≤ ω < 10°/s: 2*10⁻⁴ (10° average)
ω ≥ 10°/s: 2*10⁻⁵ (360° average)
Maximum Angular Acceleration Inner frame: ≥500°/s²
Outer frame: ≥200°/s²
User Slip Ring Customizable
Weight ≤200Kg
