2ST580-A Dual Axis Manual Digital Display Position Turntable with 40Kg Load Weight
2ST580-A Dual Axis Manual Digital Display Position Turntable with 40Kg Load Weight
2ST580-A Dual Axis Manual Digital Display Position Turntable with 40Kg Load Weight
2ST580-A Dual Axis Manual Digital Display Position Turntable with 40Kg Load Weight
2ST580-A Dual Axis Manual Digital Display Position Turntable with 40Kg Load Weight
2ST580-A Dual Axis Manual Digital Display Position Turntable with 40Kg Load Weight
2ST580-A Dual Axis Manual Digital Display Position Turntable with 40Kg Load Weight
2ST580-A Dual Axis Manual Digital Display Position Turntable with 40Kg Load Weight
2ST580-A Dual Axis Manual Digital Display Position Turntable with 40Kg Load Weight
2ST580-A Dual Axis Manual Digital Display Position Turntable with 40Kg Load Weight
Specifications
Brand Name :
RUYA
Model Number :
2ST580-A
Certification :
ISO 9001
Place of Origin :
China
MOQ :
1 set
Price :
negotiable
Payment Terms :
T/T
Supply Ability :
≤3 sets， 3 months
Delivery Time :
3-4 months
Packaging Details :
wooden box
Load Weight :
40Kg
Table Diameter :
Ф580mm
Table Flatness :
0.02mm
Table Runout :
0.02mm
Intersection :
Ф0.5mm diameter ball
Rotary Accuracy :
±3″
Perpendicularity :
±3″
Display Resolution :
0.0001°
Description
2ST580-A Dual Axis Manual Digital Display Position Turntable
Product Overview

The 2ST580-A dual-axis manual digital display position turntable is a precision measurement and positioning device featuring two independently rotatable axes. This system allows manual operation of azimuth and pitch to specific angles, with corresponding angular positions displayed by independent digital display circuits that operate without mutual interference.

Technical Specifications
Specification Value
Load Weight 40Kg
Table Diameter Ф580mm
Table Flatness 0.02mm
Table Runout 0.02mm
Rotary Accuracy Of Dual-Axis ±3″
Perpendicularity Of Dual-Axis ±3″
Intersection Of Dual-Axis Ф0.5mm diameter ball
Positioning Error Of Angular Position Outer frame: ±5″
Inner frame: ±5″
Positioning Repeatability Of Angular Position ±2″
Angle Rotary Range Inner frame: Continuous rotation
Outer frame: ±90°
Display Mode Degree: 0.0000-359.9999°
Degrees, minutes and seconds: 0°0′0″-359°59′59″
Radian: 0.0000-6.2832
Display Resolution 0.0001°
