Specifications
Model Number :
DGKYD111Q066HWA1D
Place of Origin :
Guangdong, China
Brand Name :
DGKYD
MOQ :
1
Price :
$0.60-1.80
Connector Type :
RJ45
Shielding :
YES
Number of Ports :
1
Contact Finish :
6U/15U/30U
Orientation :
Side
Number of Rows :
1
Pins :
10P
Contact Material :
Phosphor Bronze
Housing Material :
PBT Polyester
Filter :
With Filter
Performance Speed :
10/100/1000 BASE-T
Port Configuration :
Single
Terminals per Port :
8
PCB Mounting Orientation :
Side Entry (Right Angle)
Contact Mating Plating :
Gold 6u/15u/30u/50u
Description
Product Description

High-Speed 1x1 Single-Port Gigabit Network Connector Plug10PIN PBT Material Integrated Filtering Shielding Non-Lit for RJ45

Part Number
DGKYD111Q066HWA1D
Brand
DGKYD/OEM/ODM
Place of Origin
Guangdong of China
Certification
ISO16949/CE /UL/FCC/Reach/RoHS
Product Type 
Connector-Modular
Connector Style
Jack
Jack Type
RJ45
Connector Type 
Modular Jack
Latch Style
Standard
Latch
Down
Filter
With Filter
LED Option
Without LED
LED Color
N/A
Panel Stops
With Panel Stops
Shielded
Yes
Applies To 
Printed Circuit Board
Performance Speed
10/100/1000 BASE-T
Grounding Options
Panel Ground and PCB Ground
Port Configuration 
Single
Number of Positions 
10
Jack Configuration
1 x 1
Terminals per Port
8
Shield Material
Copper Alloy preplated with Nickel
PCB Mounting Orientation 
Side Entry (Right Angle)
Contact Mating Area Plating Material 
Gold 6u/15u/30u/50u
Contact Base Material 
Phosphor Bronze
Solder Tail Contact Plating Material 
Tin-Lead over Nickel
PCB Mounting Style 
Through Hole
Termination Method to PC Board 
Through Hole-Press-Fit
Board Lock
With/Without Board Lock
Housing Material 
PBT Polyester
Housing Color
Black
Housing Material  Temperature
Standard
UL Flammability Rating 
UL 94V-0
1-Port RJ45 Connector 10P PBT with Filter and Shielding1-Port RJ45 Connector 10P PBT with Filter and Shielding1-Port RJ45 Connector 10P PBT with Filter and Shielding1-Port RJ45 Connector 10P PBT with Filter and Shielding
