RJ45 Single Port Connector 100Mbps with LED Yellow Green for PCB
RJ45 Single Port Connector 100Mbps with LED Yellow Green for PCB
RJ45 Single Port Connector 100Mbps with LED Yellow Green for PCB
RJ45 Single Port Connector 100Mbps with LED Yellow Green for PCB
RJ45 Single Port Connector 100Mbps with LED Yellow Green for PCB
RJ45 Single Port Connector 100Mbps with LED Yellow Green for PCB
RJ45 Single Port Connector 100Mbps with LED Yellow Green for PCB
RJ45 Single Port Connector 100Mbps with LED Yellow Green for PCB
RJ45 Single Port Connector 100Mbps with LED Yellow Green for PCB
RJ45 Single Port Connector 100Mbps with LED Yellow Green for PCB
RJ45 Single Port Connector 100Mbps with LED Yellow Green for PCB
RJ45 Single Port Connector 100Mbps with LED Yellow Green for PCB
Specifications
Model Number :
KRJ-037NL
Place of Origin :
Guangdong, China
MOQ :
1
Price :
$0.54-0.70
Type :
RJ45
Packaging :
DIP
Gender :
Female
Housing Material :
PBT BLACK
LED Option :
Yellow&Green
Latch :
Up
Number of Ports :
1
Number of Contacts :
8
PCB Mount Angle :
SIDE ENTRY
Mount Style :
Through Hole
Performance Speed :
10/100/1000/10G BASE-T
Port Configuration :
Single
Jack Configuration :
1 x 1
Terminals per Port :
8
Shield Material :
Copper Alloy preplated with Nickel
Description
Product Description

Factory Direct Supply: Single Port, 100Mbps, LED - Equipped & Shielded RJ45 Transformer for Computer Connectors

Part Number
KRJ-037NL
Brand
DGKYD/OEM/ODM
Place of Origin
Guangdong of China
Certification
ISO16949/ISO9001/ISO14001/CE /UL/FCC/Reach/RoHS
Product Type 
Connector-Modular
Connector Style
Jack
Jack Type
RJ45
Connector Type 
Modular Jack
Latch Style
Standard
Latch
Up
Filter
With Filter
LED Option
With LED
LED Color
Yellow/Green
Panel Stops
With/Without Panel Stops
Shielded
Yes
Applies To 
Printed Circuit Board
Performance Speed
10/100/1000/10G BASE-T
Grounding Options
Panel Ground and PCB Ground
Port Configuration 
Single
Number of Positions 
8
Jack Configuration
1 x 1
Terminals per Port
8
Shield Material
Copper Alloy preplated with Nickel
PCB Mounting Orientation 
Side Entry (Right Angle)
Contact Mating Area Plating Material 
Gold 6u/15u/30u/50u
Contact Base Material 
Phosphor Bronze
Solder Tail Contact Plating Material 
Tin-Lead over Nickel
PCB Mounting Style 
Through Hole
Termination Method to PC Board 
Through Hole-Press-Fit
Board Lock
With/Without Board Lock
Housing Material 
PBT Polyester
Housing Color
Black
Housing Material  Temperature
Standard
UL Flammability Rating 
UL 94V-0

RJ45 Single Port Connector 100Mbps with LED Yellow Green for PCBRJ45 Single Port Connector 100Mbps with LED Yellow Green for PCBRJ45 Single Port Connector 100Mbps with LED Yellow Green for PCB
