DGKYD RJ45 Connector 8P Single Port Shielded with Transformer
DGKYD RJ45 Connector 8P Single Port Shielded with Transformer
DGKYD RJ45 Connector 8P Single Port Shielded with Transformer
DGKYD RJ45 Connector 8P Single Port Shielded with Transformer
DGKYD RJ45 Connector 8P Single Port Shielded with Transformer
DGKYD RJ45 Connector 8P Single Port Shielded with Transformer
DGKYD RJ45 Connector 8P Single Port Shielded with Transformer
DGKYD RJ45 Connector 8P Single Port Shielded with Transformer
DGKYD RJ45 Connector 8P Single Port Shielded with Transformer
DGKYD RJ45 Connector 8P Single Port Shielded with Transformer
DGKYD RJ45 Connector 8P Single Port Shielded with Transformer
DGKYD RJ45 Connector 8P Single Port Shielded with Transformer
Specifications
Model Number :
DGKYD111B044GWA1D
Place of Origin :
Guangdong, China
MOQ :
1
Price :
$0.45-0.70
Connector Type :
RJ45
Installation Type :
Through Hole
Contact Material :
Phosphor Bronze
Shielding :
Yes
Number of Ports :
1
Contact Finish :
6U/15U30U
Orientation :
Side
Number of Rows :
1
Pins :
8P
Housing Material :
PBT BLACK
Contact Plating :
Gold 6u'' / 15u"/ 30u"/ 50u"
Metal Shield :
TIN PLATED PHOSPHOR BROZNE
LED Option :
without LED
Latch Style :
Down
Number of Contacts :
8
Description
Product Description

Premium 1x1 Single Port RJ45 Ethernet Connector Jack LED Indicator PCB Mount Shielded Transformer Reliable Network Plug

Part Number
DGKYD111B044GWA1D
Brand
DGKYD/OEM/ODM
Place of Origin
Guangdong of China
Certification
IATF16949/ISO9001/ISO14001/
CE /UL/FCC/Reach/RoHS
Product Type 
Connector-Modular
Connector Style
Jack
Jack Type
RJ45
Connector Type 
Modular Jack
Latch Style
Standard
Latch
Down
Filter
With Filter
LED Option
Without LED
LED Color
 N/A
Panel Stops
Without Panel Stops
Shielded
Yes
Applies To 
Printed Circuit Board
Performance Speed
100 BASE-T
Grounding Options
Panel Ground and PCB Ground
Port Configuration 
Single
Number of Positions 
8
Jack Configuration
1 x 1
Terminals per Port
8
Shield Material
Copper Alloy preplated with Nickel
PCB Mounting Orientation 
Side Entry (Right Angle)
Contact Mating Area Plating Material 
Gold 6u
Contact Base Material 
Phosphor Bronze
Solder Tail Contact Plating Material 
Tin-Lead over Nickel
PCB Mounting Style 
Through Hole
Termination Method to PC Board 
Through Hole-Press-Fit
Board Lock
With/Without Board Lock
Housing Material 
PBT Polyester
Housing Color
Black
Housing Material  Temperature
Standard
UL Flammability Rating 
UL 94V-0

DGKYD RJ45 Connector 8P Single Port Shielded with TransformerDGKYD RJ45 Connector 8P Single Port Shielded with TransformerDGKYD RJ45 Connector 8P Single Port Shielded with Transformer
