3mΩ(0.003 Ohm) 2512 Current Shunt Resistor 4W ±1% ESR Ellon High Precision SMD
3mΩ(0.003 Ohm) 2512 Current Shunt Resistor 4W ±1% ESR Ellon High Precision SMD
3mΩ(0.003 Ohm) 2512 Current Shunt Resistor 4W ±1% ESR Ellon High Precision SMD
3mΩ(0.003 Ohm) 2512 Current Shunt Resistor 4W ±1% ESR Ellon High Precision SMD
3mΩ(0.003 Ohm) 2512 Current Shunt Resistor 4W ±1% ESR Ellon High Precision SMD
3mΩ(0.003 Ohm) 2512 Current Shunt Resistor 4W ±1% ESR Ellon High Precision SMD
Specifications
Supply Ability :
Large volume available
Packaging Details :
4000
Power Rating :
4W
Certification :
RoHS / REACH
Price :
Negotiable
Resistance Range :
3mΩ(0.003 Ohm)
Delivery Time :
3-5 work days
Name :
Current Shunt Resistor
Manufacturer :
Ellon
Series :
ESR
Place of Origin :
Made in China
MOQ :
4000
Tolerance :
±1%
Brand Name :
Ellon
Temperature Coefficient :
±50 ppm/°C
Applications :
Current Sensing, Power Supplies, Motor Control, Battery Management
Operating Temperature Range :
-55°C to +175°C
Features :
High Power,Low temperature
Size :
2512
Model Number :
ESR25F4WR003F04G
Payment Terms :
T/T
Material :
FeCrAl
Per Reel :
4000
Description
3mΩ (0.003 Ohm) 2512 Current Shunt Resistor 4W ±1%
Low ESR Current Shunt Resistor 4W Chip Shunt Resistor 3m Ohm ESR25F4WR003F04G. This 2512 current shunt resistor from Ellon ESR series delivers 3mΩ (0.003 Ohm) resistance with ±1% tolerance and 4W rated power, giving designers a compact surface-mount part that maintains stable performance under load and temperature variations.
Technical Specifications
NameCurrent Shunt Resistor
ManufacturerEllon
SeriesESR
Size2512
Resistance Range3mΩ (0.003 Ohm)
Tolerance±1%
Power Rating4W
Operating Temperature Range-55°C to +175°C
Temperature Coefficient±50 ppm/°C
Key Features
  • Stable 4W rated power handling for demanding circuits
  • ±1% tolerance for dependable measurement accuracy
  • Low ±50 ppm/°C temperature coefficient that maintains value stability during temperature fluctuations
  • FeCrAl element material for consistent, repeatable performance
  • Compact 2512 SMD footprint suitable for high-density reflow assembly
  • RoHS / REACH compliant construction for lead-free manufacturing
Applications
This current shunt resistor is ideal for current sensing, power supplies, motor control, and battery management systems. Its FeCrAl construction and stable electrical behavior help designers meet tight tolerances in current sensing, power conversion, and protection circuits, while the 2512 package maintains a compact layout.
Quality & Manufacturing Advantages
Sourcing directly from the manufacturer ensures competitive pricing with short lead times. Every batch undergoes electrical testing before packaging, guaranteeing that the specified resistance and tolerance values are delivered as specified.
Packaging & Quality Assurance
Supplied on tape and reel for automatic pick-and-place assembly in standard reel quantities for SMT production lines. All shipments are RoHS and REACH compliant, with certificates of compliance available upon request. Contact us for samples, datasheets, and volume pricing tailored to your project requirements.
