0.0007R (0.7m Ohm) 3920 Current Shunt Resistor 8W Ellon High Precision SMD
0.0007R (0.7m Ohm) 3920 Current Shunt Resistor 8W Ellon High Precision SMD
0.0007R (0.7m Ohm) 3920 Current Shunt Resistor 8W Ellon High Precision SMD
0.0007R (0.7m Ohm) 3920 Current Shunt Resistor 8W Ellon High Precision SMD
0.0007R (0.7m Ohm) 3920 Current Shunt Resistor 8W Ellon High Precision SMD
0.0007R (0.7m Ohm) 3920 Current Shunt Resistor 8W Ellon High Precision SMD
Specifications
Place of Origin :
Made in China
MOQ :
2000
Delivery Time :
5-8 work days
Resistance :
0.0007R (0.7m Ohm)
Temperature Coefficient :
Low
Package Size :
3920
Rated Power :
8W
Certification :
RoHS / REACH
Model Number :
ESR39F8W0M70M02G
Payment Terms :
T/T
Precision Error :
1%
Supply Ability :
Large volume available
Price :
Negotiable
Packaging Details :
Tape and reel
Operating Temperature :
-55℃ to +175℃
Brand Name :
Ellon
Description
0.0007R (0.7m Ohm) 3920 Current Shunt Resistor 8W Ellon High Precision SMD
3920 0.0007R (0.7m Ohm) 8W MnCu Metal Shunt Chip Resistor for High-Precision Current Sensing. This 3920 current shunt resistor from Ellon delivers 0.0007R (0.7m Ohm) resistance with standard tolerance and 8W rated power, giving designers a compact surface-mount part that maintains stable performance under varying load and temperature conditions.
Technical Specifications
Resistance 0.0007R (0.7m Ohm)
Temperature Coefficient Low
Operating Temperature -55℃ to +175℃
Rated Power 8W
Precision Error 1%
Package Size 3920
Model Number ESR39F8W0M70M02G
Key Features
  • Stable 8W rated power handling for demanding circuit applications
  • Low temperature coefficient maintains stable resistance values as board temperature increases
  • Compact 3920 SMD footprint suitable for high-density reflow assembly processes
  • RoHS / REACH compliant construction for lead-free manufacturing requirements
Applications
This current shunt resistor is ideal for current sensing applications, power supplies, industrial control systems, and consumer electronics. The ceramic construction and stable electrical characteristics help designers achieve tight tolerances in current sensing, power conversion, and protection circuits, while the compact 3920 package enables space-efficient PCB layouts.
Manufacturing Advantages
Sourcing directly from the manufacturer ensures competitive pricing with short lead times. Every production batch undergoes comprehensive electrical testing prior to packaging, guaranteeing that the specified resistance and tolerance values are precisely maintained in the delivered components.
Packaging & Quality Assurance
Supplied on tape and reel packaging for automated pick-and-place assembly systems, in standard reel quantities optimized for SMT production lines. All shipments comply with RoHS and REACH environmental standards and include certificate of compliance documentation upon request. Contact us for product samples, detailed datasheets, and volume pricing tailored to your specific project requirements.
0.0007R (0.7m Ohm) 3920 Current Shunt Resistor 8W Ellon High Precision SMD
Application reference: 3920 0.0007R (0.7m Ohm) 8W MnCu Metal Shunt Chip Resistor
