0.0004R (0.4m Ohm) 2512 Current Shunt Resistor 6W 1% Ellon High Precision SMD
0.0004R (0.4m Ohm) 2512 Current Shunt Resistor 6W 1% Ellon High Precision SMD
0.0004R (0.4m Ohm) 2512 Current Shunt Resistor 6W 1% Ellon High Precision SMD
0.0004R (0.4m Ohm) 2512 Current Shunt Resistor 6W 1% Ellon High Precision SMD
0.0004R (0.4m Ohm) 2512 Current Shunt Resistor 6W 1% Ellon High Precision SMD
0.0004R (0.4m Ohm) 2512 Current Shunt Resistor 6W 1% Ellon High Precision SMD
Specifications
Certification :
RoHS / REACH
Price :
Negotiable
Package Size :
2512 (6.3mm × 3.2mm)
Operating Temperature :
-55°C to +175°C
Brand Name :
Ellon
Tolerance :
1%
Place of Origin :
Made in China
Temperature Coefficient :
±20ppm/°C
Payment Terms :
T/T
Supply Ability :
Large volume available
Power Rating :
6W
Resistance :
0.0004R (0.4m Ohm)
Delivery Time :
5-8 work days
Packaging Details :
Tape and reel
Model Number :
ESR25F6W0M40M04G
MOQ :
4000
Description
0.0004R (0.4m Ohm) 2512 Current Shunt Resistor 6W 1%
2512 0.0004R (0.4m Ohm) 6W 1% Metal Shunt Chip Resistor for High-Current Sensing with MnCu Alloy. This 2512 current shunt resistor from Ellon delivers 0.0004R (0.4m Ohm) resistance with 1% tolerance and 6W rated power, giving designers a compact surface-mount part that keeps performance steady under load and temperature.
Technical Specifications
Parameter Specification
Resistance 0.0004R (0.4m Ohm)
Package Size 2512 (6.3mm × 3.2mm)
Power Rating 6W
Tolerance 1%
Operating Temperature -55°C to +175°C
Temperature Coefficient ±20ppm/°C
Model Number ESR25F6W0M40M04G
Key Features
  • Stable 6W rated power handling for demanding circuits
  • 1% tolerance for dependable measurement accuracy
  • Low ±20ppm/°C temperature coefficient that keeps values stable as the board heats up
  • Compact 2512 SMD footprint suitable for high-density reflow assembly
  • RoHS / REACH compliant construction for lead-free manufacturing
Applications
This current shunt resistor suits current sensing, power supplies, industrial control and consumer electronics. Its ceramic construction and stable electrical behaviour help designers meet tight tolerances in current sensing, power conversion and protection circuits, while the 2512 body keeps the layout compact.
Why Choose This Part
Buying directly from the manufacturer keeps the series available at competitive pricing with short lead times. Every batch is electrically tested before packing, so the resistance and tolerance you specify are the values you receive.
Packaging & Quality Assurance
Supplied on tape and reel for automatic pick-and-place assembly, in standard reel quantities for SMT lines. Every shipment is RoHS and REACH compliant and can be accompanied by a certificate of compliance on request. Contact us for samples, datasheets and volume pricing tailored to your project.
0.0004R (0.4m Ohm) 2512 Current Shunt Resistor 6W 1% Ellon High Precision SMD
Application reference: 2512 0.0004R (0.4m Ohm) 6W 1% Metal Shunt Chip Resistor
