Cryogenic Liquid Carbon Dioxide Storage Tank Capacity Expansion Customization
Cryogenic Liquid Carbon Dioxide Storage Tank Capacity Expansion Customization
Cryogenic Liquid Carbon Dioxide Storage Tank Capacity Expansion Customization
Cryogenic Liquid Carbon Dioxide Storage Tank Capacity Expansion Customization
Cryogenic Liquid Carbon Dioxide Storage Tank Capacity Expansion Customization
Cryogenic Liquid Carbon Dioxide Storage Tank Capacity Expansion Customization
Cryogenic Liquid Carbon Dioxide Storage Tank Capacity Expansion Customization
Cryogenic Liquid Carbon Dioxide Storage Tank Capacity Expansion Customization
Specifications
Brand Name :
GNEE
Certification :
SGS
Place of Origin :
CHINA
MOQ :
≥1sets
Payment Terms :
L/C,T/T
Supply Ability :
Annual Production 30,000
Delivery Time :
Transit time: Est. 17-24 days
Packaging Details :
Wooden box packaging / Outer shell packaging / Cylindrical packaging / Airbag packaging
Capacity :
30 m3,100-20000L
Weight :
customized,Actual Weight
Warranty :
1 Year
Condition :
New
Dimension(l*w*h) :
2991mm X 2438mm X 2591mm,according to capacity
Material :
Stainless Steel,carbon steel
Color :
based on customer's requirement
Type :
vertical
Usage :
cryogenic liquid storage,liquid gas storage tank,Cryogenic Storage Tank,cryogenic storage dewar
Application :
pharmaceutical,Fuel Oil,Cold storage,Chemical,juice
Product name :
Stainless Steel storage Tank
Working pressure :
1-40Mpa
Working medium :
LN2,LO2,LPG,LNG,
Design temperature :
-196°C/50°C
Description

Cryogenic Liquid Carbon Dioxide Storage Tank Capacity Expansion


Description

The low temperature liquid carbon dioxide storage tank is double-walled, the inner material is 16MnDR, and the outer material is Q345R, carbon steel. It adopts vertical and horizontal structure, adopts vacuum powder insulation, and has the advantages of compact structure, low release date, small footprint, centralized control, safety and reliability, and convenient operation and maintenance.

Cryogenic Liquid CO2 Storage Tank Specification

Volume (M3)

Working pressure(bar)

Dimension

(mm)

Weight

(KG)

Type

Standard

5

21.6

Φ2000*5130

4450

Vertical

GB

ASME

10

21.6

Φ2100*7170

6986

15

21.6

Φ2500*6912

8810

20

21.6

Φ2500*8756

11328

25

21.6

Φ2900*7728

17961

30

21.6

Φ2900*8875

14660

50

21.6

Φ3200*11320

26097

60

21.6

Φ3200*13180

30220

100

21.6

Φ3500*16870

49627


Cryogenic Liquid Carbon Dioxide Storage Tank Capacity Expansion Customization

Cryogenic Liquid Carbon Dioxide Storage Tank Capacity Expansion Customization

Cryogenic Liquid Carbon Dioxide Storage Tank Capacity Expansion Customization

Structural composition

Cryogenic Liquid Carbon Dioxide Storage Tank Capacity Expansion Customization

Inner container: an inner tank that storesrefrigerated gas and can withstandworking pressure.

Enclosure: A sealed container that formsand protects a vacuum insulated space.Mezzanine: refers to the enclosed spaceformed between the inner container andthe outer shell.

Tank: a pressure vessel composed of an

inner container, an outer shell and aninsulation layer.

FAQ

Q:Do you accept product customization?

A:Of course, we are running our own factory, accept OEM product customization services, you can send your specific requirements to us, we have a professional design engineer to provide you with customized design services.

Q:What is the service life of your product?

A: Designed service life of 20 years; It can be extended according to the actual use situation. Some of our customers have used it for 30 years.

Q:Can I put my logo on the product?

A:We support product painting color and logo customization.
