Q345R Cryogenic Liquid Carbon Dioxide Storage Tanks 20m3
Q345R Cryogenic Liquid Carbon Dioxide Storage Tanks 20m3
Q345R Cryogenic Liquid Carbon Dioxide Storage Tanks 20m3
Q345R Cryogenic Liquid Carbon Dioxide Storage Tanks 20m3
Q345R Cryogenic Liquid Carbon Dioxide Storage Tanks 20m3
Q345R Cryogenic Liquid Carbon Dioxide Storage Tanks 20m3
Q345R Cryogenic Liquid Carbon Dioxide Storage Tanks 20m3
Q345R Cryogenic Liquid Carbon Dioxide Storage Tanks 20m3
Specifications
Brand Name :
GNEE
Certification :
SGS
Place of Origin :
China
MOQ :
≥1sets
Payment Terms :
L/C, T/T
Supply Ability :
Annual Production 30,000
Delivery Time :
Transit time: Est. 17-24 days
Packaging Details :
Single item
Height :
2591mm
Other Name :
Cryogenic Liquid Co2 Gas Storage Tank
Working Years Design :
20years
Outer Material :
Q345R
Insulation Material :
Vacuum Insulated
Test Pressure :
0.8MPa-1.6MPa
Function :
Low temperature storage
Advantage :
long life/duable
Weight :
~15400kg
Design Pressure :
0.8 MPa
Item :
cryogenic storage tank
Type :
customization
Description

Cryogenic Liquid Carbon Dioxide Storage Tanks 20m³

Description

The low-temperature liquid carbon dioxide storage tank adopts a double-layer container structure. The inner container is made of 16MnDR low-temperature steel, the outer container is made of Q235-B or Q345R carbon structural steel, and the interlayer is subjected to vacuum treatment.

  • Compliant with ASME code.
  • The design pressure of the tanks reaches 22 bar (PED) or 24 bar (ASME).
  • Capacities between 3,000 L and 63,000 L, depending on the customer’s specifications.
  • Fitted with support legs, they resist high winds and earthquakes.

Parameter

Carbon Dioxide Storage Tanks
Available volume 20 m³
Geometric volume 21.05 m³
Max working pressure 21.6 bar
Design temperature -40°C
Medium LCO₂
Main body material 16MnDR/Q235
Safety valve set pressure 22.7 bar

Q345R Cryogenic Liquid Carbon Dioxide Storage Tanks 20m3

Q345R Cryogenic Liquid Carbon Dioxide Storage Tanks 20m3

Q345R Cryogenic Liquid Carbon Dioxide Storage Tanks 20m3

Liquid CO₂ gas tanks are generally used for

  • Used in the production of the alkali industry, sugar industry, and carbonated beverages.
  • Used for the quenching of steel castings and the manufacture of lead white.
  • Widely used in the field of welding.
  • Use carbon dioxide spray paint; it dries quickly, has a good gloss, and has no toxic pollution. industrial CO₂ tank.
  • Low concentration of carbon dioxide can promote breathing, so it can be used for medical treatment.

ABOUT US

GNEE has its own product manufacturing factory with 60 years of manufacturing experience. The company covers an area of 80,000 square meters, among which the production area occupies 20,000 square meters, with an annual production capacity of about 30,000 tons of pressure vessels.

The factory has an independent R&D center, which includes 2 senior engineers, 17 engineers, and 10 assistant engineers.
