Specifications
Brand Name :
GNEE
Certification :
SGS
Place of Origin :
CHINA
MOQ :
≥1sets
Price :
According to the product
Payment Terms :
L/C,T/T,D/P,Western Union,MoneyGram,D/A
Packaging Details :
customized
Structure :
VPSA Oxygen Generator Industrial Use
Test Pressure :
0.8MPa-1.6MPa
Process :
VPSA
Operation Mode :
Automatic
Capacity :
5-5000 Nm3/h
Voltage :
220v/380v/50-60hz
Nitrogen Output :
≤300Nm3/hr
Consumption :
Energy-saving
Outer Vessel Material :
Carbon Steel
Operating Pressure :
0.1-0.6 MPa
Oil Content :
Oil free
Operate Power :
1 KW
Purity :
90-95%
Key Words :
VPSA oxygen generator
Description
Hot Sell PSA /VPSA/VSA /Cryogenic Small and Large Oxygen Generator

VPSA Oxygen Generator

Purity: 90%-93%

Capacity: 200~20000Nm3/h

Pressure: Normal 0.4Mpa

Energy for Consumption Oxygen:0.36~0.42KWh/Nm

The VPSA precess is similar with PSA. VPSA oxygen generator use air blower to supply compressed air into a adsorption tower, adsorption in low pressure and adsorption in vacuum status. Under atmosphere or slightly abover atmosphere pressure, using mixed bed composed of VPSA special molecular sieve and dryer to absorb the N2,CO2.H2O and other impurities, making oxygen accumulated and collected at the end of bed .Saturation sorption of molecular sieve bed will be desorbed in vacuum status ,so as to circularly generate high purity Oxygen . (90~95%).

Compared with PSA process, VPSA has complex process equopment and higher investment but low power consumption, suitable for large scale oxygen production.

Product Parameters

Gas production m³/h

Oxygen concentration%

Oxygen pressure Mpa

Power 220V Power/kw

Host weight/kg

Dimensions/mm

Air loss factor

Number of bottles per day 40L/120-150kg

3

93±3

0.4±0.1

0.2

600

15009001500

13.5

12-15

5

93±3

0.4±0.1

0.2

900

16009001500

13.5

20-24

10

93±3

0.4±0.1

0.2

1200

16009001900

13.5

40-48

20

93±3

0.4±0.1

0.2

1500

190010002180

13.5

80-96

30

93±3

0.4±0.1

0.2

2000

200011002180

13.5

120-154

40

93±3

0.4±0.1

0.2

2500

260012002300

13.5

160-192

50

93±3

0.4±0.1

0.5

2800

180015002400+800

13.5

200-240

60

93±3

0.4±0.1

0.5

3200

180015002600+800

13.5

240-184

70

93±3

0.4±0.1

0.5

3500

180016002800+800

13.5

280-236

80

93±3

0.4±0.1

0.5

4000

180016002900+1000

13.5

320-394

90

93±3

0.4±0.1

0.5

4800

200016002800+1000

13.5

360-432

100

93±3

0.4±0.1

0.5

5800

220016002900+1000

13.5

400-480

120

93±3

0.4±0.1

0.5

6500

240016003100+1000

13.5

480-576

Hot Sell PSA /VPSA/VSA /Cryogenic Small and Large Oxygen Generator

Hot Sell PSA /VPSA/VSA /Cryogenic Small and Large Oxygen Generator

Hot Sell PSA /VPSA/VSA /Cryogenic Small and Large Oxygen Generator


Technical Feature

Fully automatic control system.

The energy consumption is low,low Production Cost

Simple Process and Less Equipment

Quick Starting and Easy Stopping.

Suitable for middle and large scale oxygen production.

Low working pressure and more safety.

Long Life and low maintenance.


Packaging

Size

123 (L) * 456 (W) * 789 (D)

Weight

1.2 T

Packaging Details

The normal package is wooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.


In addition to PSA Oxygen Generators, we also produce VPSA Oxygen Generators, storage tanks, heat exchangers and other products. If you are interested in VPSA Oxygen Systems or other products, please feel free to send an email to info@gneeheatex.com. We will be very happy to serve you.
