High Efficiency VPSA Oxygen Generator with 0.8MPa-1.6MPa Test Pressure and 5-45°C Operating Temperature for Medical and Industrial Use
High Efficiency VPSA Oxygen Generator with 0.8MPa-1.6MPa Test Pressure and 5-45°C Operating Temperature for Medical and Industrial Use
High Efficiency VPSA Oxygen Generator with 0.8MPa-1.6MPa Test Pressure and 5-45°C Operating Temperature for Medical and Industrial Use
High Efficiency VPSA Oxygen Generator with 0.8MPa-1.6MPa Test Pressure and 5-45°C Operating Temperature for Medical and Industrial Use
High Efficiency VPSA Oxygen Generator with 0.8MPa-1.6MPa Test Pressure and 5-45°C Operating Temperature for Medical and Industrial Use
High Efficiency VPSA Oxygen Generator with 0.8MPa-1.6MPa Test Pressure and 5-45°C Operating Temperature for Medical and Industrial Use
High Efficiency VPSA Oxygen Generator with 0.8MPa-1.6MPa Test Pressure and 5-45°C Operating Temperature for Medical and Industrial Use
High Efficiency VPSA Oxygen Generator with 0.8MPa-1.6MPa Test Pressure and 5-45°C Operating Temperature for Medical and Industrial Use
Specifications
Brand Name :
GNEE
Certification :
SGS
Place of Origin :
CHINA
MOQ :
≥1sets
Price :
According to the product
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Packaging Details :
Sea or land transportation
Key Words :
VPSA oxygen generator
Test Pressure :
0.8MPa-1.6MPa
Area Covered :
~600m2
Output Pressure :
10-15Kap or as user's requirement
Operating Temperature :
5-45°C
Pressure :
0.05Mpa or adjustable
Maintenance Cycle :
≥8000 hours
Flow Rate :
100-10000Nm3/h
Working Principle :
Vacuum Pressure Swing Adsorption
Consumption :
Energy-saving
Description
High End Vpsa Oxygen Generator for Hospital O2 Separation Plant Medical Oxigen Generator Station

Product Description

Our VPSA Oxygen Production Equipment uses advanced adsorption gas separation technology to efficiently produce 80%-94% oxygen, widely used in industries such as steel, glass, and paper.

The VPSA (Vacuum Pressure Swing Adsorption) oxygen production equipment transports low-pressure air through a blower, purifies it, and then enters the adsorption tower. Special molecular sieves are used to adsorb nitrogen and moisture, enriching oxygen. The equipment features high efficiency, energy-saving, high automation, small footprint, and easy start-stop.

Product Parameters

90%

93%

APPROX. WEIGHT AND DIMENSIONS

SCFH

NM3/HR

SCFH

NM3/HR

H

W

L

WEIGHT

Inch

Inch

Inch

Lbs.

73

1.92

65

1.71

86

36

30

720

111

2.93

100

2.62

87

36

37

780

164

4.31

147

3.86

87

42

48

1728

207

5.44

185

4.86

93

42

48

1927

311

8.19

278

7.32

103

46

48

2630

414

10.89

371

9.74

106

50

53

4892

516

13.57

461

12.13

110

52

58

3851

724

19.03

647

17.02

97

54

60

4592

1237

32.52

1106

29.10

121

72

72

7576

1641

43.15

1468

38.60

116

74

88

9370

2107

55.40

1885

49.56

137

74

88

10882

2521

66.28

2255

59.29

135

84

112

15238

2918

76.72

2610

68.63

127

90

112

15602

3706

97.45

3315

87.18

147

90

112

16699

4101

107.83

3668

96.46

121

120

156

19988

4473

117.63

4002

105.23

127

120

156

20791

5033

132.33

4502

118.38

184

120

156

21774

High Efficiency VPSA Oxygen Generator with 0.8MPa-1.6MPa Test Pressure and 5-45°C Operating Temperature for Medical and Industrial Use

High Efficiency VPSA Oxygen Generator with 0.8MPa-1.6MPa Test Pressure and 5-45°C Operating Temperature for Medical and Industrial Use

High Efficiency VPSA Oxygen Generator with 0.8MPa-1.6MPa Test Pressure and 5-45°C Operating Temperature for Medical and Industrial Use

Application

Industrial oxygen generator used for aquaculture, welding, cutting or feeding oxygen to ozone machine etc.

1.Medical: The generator can be set up to fill the hospital pipeline directly and use the filling ramp as a backup system. Oxygen cylinders can be filled simultaneously or during hours with low consumption.

2.Metallurgy: For anneal protection, agglomeration protection, nitrogenizing, furnace washing and blowing, etc. Used in fields such as metal heating treatment, powder metallurgy, magnetic material, copper process, metallic mesh, galvanized wire, semiconductor, etc.

3.Chemical and new material industries: For chemical material gas, pipeline blowing, gas replacement, gas protection, product transport, etc. Used in fields such as chemical, urethane elastic fiber, rubber, plastic, tyre, polyurethane, biological technology, intermediate, etc.

4.Electronic industry: For encapsulation, agglomeration, anneal, deoxidization, storage of electronic products. Used in fields such as peak welding, circumfluence welding, crystal, piezoelectricity, electronic porcelain, electronic copper tape, battery, electronic alloy material, etc.

Packaging

Size

123 (L) * 456 (W) * 789 (D)

Weight

1.2 T

Packaging Details

The normal package is wooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.


In addition to VPSA Oxygen Generators, we also produce PSA Oxygen Generators, storage tanks, heat exchangers and other products. If you are interested in VPSA Oxygen Systems or other products, please feel free to send an email to info@gneeheatex.com. We will be very happy to serve you.
