CAF S-AFT Sanitary Pressure Transmitter 316L Stainless Steel Digital Display 4-20mA/RS485 Output
CAF S-AFT Sanitary Pressure Transmitter 316L Stainless Steel Digital Display 4-20mA/RS485 Output
Specifications
Model Number :
CAF S-AFT Pressure Feeder Controller
Operatingtemperature :
-20°C to 85°C
Brand Name :
CAF
Mountingtype :
Panel Mount, Wall Mount
MOQ :
1
Delivery Time :
2-4weeks
Productname :
Pressure Measurement Instruments
Mountingoptions :
Panel, Wall, Pipe
Payment Terms :
T/T
Applications :
Industrial, Automotive, HVAC, Oil & Gas
Mounting :
Panel mount or pipe mount
Pressuretype :
Gauge, Absolute, Differential
Calibration :
Factory Calibrated, Field Calibratable
Price :
220-380USD
Material :
Stainless Steel, Brass
Accuracy :
±0.25% of full scale
Certification :
CO
Ingressprotection :
IP65
Place of Origin :
China
Powersupply :
24 V DC
Packaging Details :
Standard cardboard box packaging
Outputsignal :
4-20 mA, 0-10 V, Digital
Supply Ability :
99pcs/2-4weeks
Pressurerange :
0 to 10000 psi
Measurementrange :
0 to 1000 psi
Description

Product Description

The S-AFC1 Sanitary Pressure Transmitter is a high-precision, food-grade pressure controller designed for hygienic applications in food, beverage, pharmaceutical, and biotech industries. Built with 316L stainless steel housing and a polished sanitary clamp connection, it meets strict hygiene standards and prevents contamination in sensitive production environments.

Equipped with a clear digital display and intuitive SET/navigation buttons, it allows on-site parameter adjustment and real-time pressure monitoring. It supports multiple output signals including 4-20mA, RS485, and HART, with options for 5-wire or 3-wire current output, compatible with most industrial PLC and control systems.

Key advantages:

  • ✅ Sanitary Design: Tri-clamp connection (φ50.5/φ25.4), Ra 0.4µm polished finish, FDA-approved fill fluid available.
  • ✅ High Precision & Stability: 0.2/0.5% accuracy grade, long-term stable performance for continuous operation.
  • ✅ Strong Anti-Interference: EMC-compliant design works reliably in complex industrial environments.
  • ✅ Fast Response: Quick signal processing for accurate pressure control in feeding/processing systems.
  • ✅ Flexible Wiring: Standard M12×4 aviation plug cable for easy installation and maintenance.
Item Specification
Model S-AFC1 Sanitary Pressure Transmitter
Core Sensor High-precision pressure sensor (0.2/0.5% F.S.)
Housing Material 316L Stainless Steel
Connection Type Sanitary Tri-clamp (φ50.5/φ25.4/φ64, custom available)
Output Signals 4-20mA / RS485 / 4-20mA+HART
Wiring Options 3-wire current output / 5-wire multi-function output
Standard Cable M12×4 aviation plug outlet
Display Digital LCD with SET button interface
Anti-Interference EMC certified, industrial EMI resistance
Operating Temp -10°C ~ +60°C
Protection Grade IP67

Applications:

  • Food & beverage processing lines (liquid feeding, pressure monitoring)
  • Pharmaceutical and biotech manufacturing systems
  • Sanitary pipeline pressure control
  • Hygienic tank/fermenter pressure monitoring
  • Industrial automatic feeding systems requiring high hygiene standards
