Specifications
Brand Name :
HONEYWELL
Model Number :
STG84L-E1G000-1-C-CHB-12C-B-00A6-FX,F1,F5,TP-0000
Certification :
CO
Place of Origin :
CHINA
MOQ :
1
Price :
640$
Payment Terms :
T/T
Delivery Time :
1WEEK
Model :
STG84L
Process Head Material :
316 Stainless Steel
Barrier Diaphragm Material :
316L SS
Fill Fluid :
Silicone Oil 200
Process Connection :
1/2" NPT (female)
Housing Material :
Polyester Powder Coated Aluminum
Output Protocol :
HART Protocol
Accuracy :
Standard
Description
HONEYWELL PRESSURE TRANSMITTER - STG84L-E1G000-1-C-CHB-12C-B-00A6-FX,F1,F5,TP-0000
Product Overview: Gauge In-Line Pressure Transmitter from Honeywell. New & Original in Factory Packing with 12 Months Factory Warranty.
Technical Specifications
Feature Code Description
Model STG84L Gauge In-Line Pressure Transmitters
Process Head & Diaphragm Materials E Process Head/Reference Head Material: 316 Stainless Steel / 316 Stainless Steel
Barrier Diaphragm Material: 316L SS
Fill Fluid 1 Silicone Oil 200
Process Connection G Size/Type: 1/2" NPT (female)
Material: Same as Process Head
Bolt/Nuts Materials 0 None
Vent/Drain Type/Location 0 Head Type: None
Vent Type: None
Location: None
Vent Material: None
Gasket Materials 0 None
Head/Connect Orientation 1 High Side Left, Low Side Right / Standard Head Orientation
Approvals C ATEX Explosion proof, Intrinsically Safe & Non-incendive
Electronic Housing Material & Connection Type B Material: Polyester Powder Coated Aluminum
Connection: M20
Lightning Protection: None
Output/Protocol H Analog Output: 4-20mA dc
Digital Protocol: HART Protocol
Customer Interface Selections B Indicator: Basic
Ext Zero, Span & Config Buttons: None
Languages: EN
Application Software 1 Standard Diagnostics
Output Limit, Failsafe & Write Protect Settings 1 Write Protect: Disabled
Fail Mode: High > 21.0mAdc
High & Low Output Limits: Honeywell Standard (3.8 - 20.8 mAdc)
General Configuration S Factory Standard
Accuracy and Calibration B Accuracy: Standard
Calibrated Range: Custom (Unit Data Required)
Calibration Qty: Single Calibration
Mounting Bracket 2 Bracket Type: Angle Bracket
Material: 304 SS
Customer Tag 1 One Wired Stainless Steel Tag (Up to 4 lines 26 char/line)
Unassembled Conduit Plugs & Adapters A0 No Conduit Plugs or Adapters Required
Certifications & Warranty FX, F1, 02 EN10204 Type 3.1 Material Traceability (FC33341)
Calibration Test Report & Certificate of Conformance (F3399)
Extended Warranty Additional 2 years
Factory 0000 Factory Identification
Important Notes
  • Reference head available with Dual Head Gage models only. In-Line Gage models are supplied with Process Head only.
  • STG830,840,870 supplied via 1/2" flange adapter same material as process head except carbon steel shall use 316 SS.
  • Left side/Right side as viewed from the customer connection perspective.
  • NAMUR Output Limits are configurable by customer.
Order & Delivery Information:
Estimated Lead Time: 12 - 16 Weeks
Shipping Weight: 10 Kg
