MPM4503 Pressure Transmitter With Silicon Micro Melting Technology Sensor Core
MPM4503 Pressure Transmitter With Silicon Micro Melting Technology Sensor Core
MPM4503 Pressure Transmitter With Silicon Micro Melting Technology Sensor Core
MPM4503 Pressure Transmitter With Silicon Micro Melting Technology Sensor Core
MPM4503 Pressure Transmitter With Silicon Micro Melting Technology Sensor Core
MPM4503 Pressure Transmitter With Silicon Micro Melting Technology Sensor Core
Specifications
Model Number :
MPM4503
Certification :
CO
Place of Origin :
china
MOQ :
1
Price :
10-100usd
Payment Terms :
T/T
Supply Ability :
99pcs 1-2 weeks
Delivery Time :
5-7 work days
Responsetime :
≤ 1 ms
Pressuretype :
Gauge, Absolute, Differential
Material :
Stainless Steel
Productname :
Pressure Measurement Instruments
Application :
Industrial process control, HVAC, Hydraulic systems
Protectionrating :
IP65
Accuracy :
±0.25% FS
Powersupply :
24 V DC
Calibration :
Factory calibrated
Connectiontype :
1/4 inch NPT
Displaytype :
Digital LCD
Mountingoptions :
Panel mount, Pipe mount
Operatingtemperature :
-20°C to 85°C
Measurementrange :
0 to 1000 psi
Outputsignal :
4-20 mA
Description
MPM4503 Pressure Transmitter
A cost-effective pressure transmitter utilizing silicon micro melting technology sensor core and specially customized amplification circuit for reliable performance.
Performance Specifications
Pressure Range & Type
Range: 0MPa to 1MPa, 1.6MPa, 2MPa, 2.5MPa, 5MPa
Pressure Type: Gauge pressure, Seal gauge pressure
Pressure Limits
Overload: ≤ 1.5 * FS
Destructive Pressure: ≤ 5 * FS (maximum 10MPa)
Accuracy & Stability
Accuracy: ≤ ±1% FS
Long Term Stability: <0.3% FS/year
Temperature Specifications
Compensation Temperature: 0℃ to 70℃
Working Temperature: -10℃ to 80℃
Storage Temperature: -40℃ to 100℃
Environmental Durability
Vibration: 5g, 10Hz to 500Hz (GB/T2423.10/IEC60068-2-6)
Impact: 10g, 11ms (GB/T2423.5/IEC60068-2-27)
Insulation Resistance: 100MΩ, 500V
Protection Level
  • IP65
  • IP68
Weight: ≤ 60g
Output Parameters
Output Signal Power Supply Voltage Output Form Load Resistance Transmission Distance
4mA~20mA DC (E) 10V~28V DC Two-wire system ≤ (U-10)/0.02 (Ω) < 1000m (@ 24V DC, Load 250Ω)
0.5V～4.5V DC (K1)
0.5V～2.5V DC (W1)		 5V±0.1V DC Three-wire system ≥ 10kΩ ≤ 5m
0.5V～2.5V DC (W) 3.3V±0.1V DC
Electromagnetic Compatibility (EMC)
Serial No. Testing Projects Execution Standards
1 Electrostatic Discharge Immunity GB/T 17626.2/IEC 61000-4-2
2 Radio Frequency Magnetic Field GB/T 17626.3/IEC 61000-4-3
3 Power Frequency Magnetic Field GB/T 17626.8/IEC 61000-4-8
4 Electrical Fast Pulse Group Immunity (Power Port) GB/T 17626.4/IEC 61000-4-4
5 Surge Immunity (Power Port) GB/T 17626.5/IEC 61000-4-5
6 Conducted Sine Wave Radio Frequency Interference (Power Port) GB/T 17626.6/IEC 61000-4-6
Process Connection
Process Connection Shape (in millimeters)
  • C2 (G1/4 external thread, end face seal)
  • C6 (NPT1/4 external thread)
