7007C-2RZ P4A Super Precision Angular Contact Ball Bearing 35x62x14mm Sealed 2RZ for High-Speed Spindles
7007C-2RZ P4A Super Precision Angular Contact Ball Bearing 35x62x14mm Sealed 2RZ for High-Speed Spindles
7007C-2RZ P4A Super Precision Angular Contact Ball Bearing 35x62x14mm Sealed 2RZ for High-Speed Spindles
7007C-2RZ P4A Super Precision Angular Contact Ball Bearing 35x62x14mm Sealed 2RZ for High-Speed Spindles
7007C-2RZ P4A Super Precision Angular Contact Ball Bearing 35x62x14mm Sealed 2RZ for High-Speed Spindles
7007C-2RZ P4A Super Precision Angular Contact Ball Bearing 35x62x14mm Sealed 2RZ for High-Speed Spindles
7007C-2RZ P4A Super Precision Angular Contact Ball Bearing 35x62x14mm Sealed 2RZ for High-Speed Spindles
7007C-2RZ P4A Super Precision Angular Contact Ball Bearing 35x62x14mm Sealed 2RZ for High-Speed Spindles
Specifications
Part Number :
7007C-2RZ P4A Precision Angular Contact Ball Bearing
Brand Name :
OEM
Model Number :
7007C-2RZ Precision Angular Contact Ball Bearing
Certification :
IATF16949:2016
Place of Origin :
China
MOQ :
100
Price :
Please contact us
Supply Ability :
100000pcs per month
Packaging Details :
plastic bag,box,carton,pallet
Seals Type :
Sealed 2RZ
Seals Color :
Black
Lubrication :
Grease
Type :
Angular Contact Ball Bearing
Contact Angle :
15°
Delivery Time :
30 days
Tolerance Class :
P4A
Preload :
Extra light / Class A
Interchangeable With :
SKF
Matched Arrangement :
2 Bearings
Description
7007C-2RZ P4A Super Precision Angular Contact Ball Bearing Single Row 35x62x14mm
Product Overview

The 7007C-2RZ P4A Super Precision Angular Contact Ball Bearing represents the pinnacle of advanced materials science, mechanical engineering, and precision manufacturing. Designed specifically for high-speed spindles, precision instruments, and applications where accuracy and speed are critical, this bearing delivers exceptional performance in demanding environments.

Technical Specifications
Bearing Number Dimensions (mm) Basic Load Rating (N) Limiting Speed (rpm) Weight (Kg)
7007C-2RZ Inner Diameter: 35 Dynamic: 19500 Grease: 8500 0.150
Outer Diameter: 62 Static: 14200 Oil: /
Width: 14
Chamfer rsmin: 1
Chamfer r1smin: 0.6
Design Features & Specifications
Ring Material Steel
Roller Material Steel, Ceramic available
Cage Material Bakelite Phenolic
Contact Angle 15°, 25° & 40° available
Lubrication Required
Matched Arrangement Available
Preload Available
Number of Bearings in Matched Set 2
Universal Matching Bearing Yes, DB, DF, DT (Back to Back, Face to Face, Tandem)
Temperature Range -30°C ~ +110°C
ABEC Rating P4 (ABEC7) P5, P2 available
Certificate RoHS, IATF16949:2016
For Load Direction Angular Contact
Service OEM & ODM Customized Services
Samples Please Contact Us
Service Support Online Support, Professional Service
Size Standard, For custom sizes please contact us
Factory Manufacturer Yes
7007C-2RZ P4A Super Precision Angular Contact Ball Bearing 35x62x14mm Sealed 2RZ for High-Speed Spindles 7007C-2RZ P4A Super Precision Angular Contact Ball Bearing 35x62x14mm Sealed 2RZ for High-Speed Spindles
Key Design Features
  • Dimensions: Bore Diameter: 35 mm, Outer Diameter: 62 mm, Width: 14 mm
  • Material Quality: Crafted from high-quality materials to ensure durability and reliability under demanding conditions
  • Precision Manufacturing: Manufactured to extremely tight tolerances, ensuring superior dimensional and geometric accuracy
  • High-Speed Capability: Optimized for high-speed operation with minimal heat generation and friction
  • Load Capacity: Capable of handling both radial and axial loads efficiently with angular contact design
  • Preload Options: Available with various preload options to enhance stiffness and reduce play
  • Surface Finish: Superior surface finish on raceways and rolling elements reduces noise and extends service life

This bearing is an essential component in industries that demand high precision and performance, including machine tool spindles, high-speed machinery, aerospace components, medical equipment, semiconductor manufacturing, automotive industry, and scientific instruments.
