7000C-2RZ Precision Angular Contact Ball Bearing 10x26x8mm P4 Precision Sealed 2RZ for Spindle Tools
7000C-2RZ Precision Angular Contact Ball Bearing 10x26x8mm P4 Precision Sealed 2RZ for Spindle Tools
7000C-2RZ Precision Angular Contact Ball Bearing 10x26x8mm P4 Precision Sealed 2RZ for Spindle Tools
7000C-2RZ Precision Angular Contact Ball Bearing 10x26x8mm P4 Precision Sealed 2RZ for Spindle Tools
7000C-2RZ Precision Angular Contact Ball Bearing 10x26x8mm P4 Precision Sealed 2RZ for Spindle Tools
7000C-2RZ Precision Angular Contact Ball Bearing 10x26x8mm P4 Precision Sealed 2RZ for Spindle Tools
7000C-2RZ Precision Angular Contact Ball Bearing 10x26x8mm P4 Precision Sealed 2RZ for Spindle Tools
7000C-2RZ Precision Angular Contact Ball Bearing 10x26x8mm P4 Precision Sealed 2RZ for Spindle Tools
Specifications
Brand Name :
OEM
Model Number :
7000C-2RZ Precision Angular Contact Ball Bearing
Certification :
IATF16949:2016
Place of Origin :
China
MOQ :
100
Price :
Please contact us
Supply Ability :
500000pcs per month
Delivery Time :
30 days
Packaging Details :
plastic bag,box,carton,pallet
Preload :
Light
Seals Color :
Red and Black
Part Number :
7000C-2RZ Precision Angular Contact Ball Bearings
Contact Angle :
15°/C angle
Tolerance Class :
P4
Interchangeable With :
SKF
Sealed Type :
2RZ
Lubrication :
Grease
Description
7000C-2RZ Spindle Ball Bearing 10x26x8 For Sealed Spindle Tools
7000C-2RZ Precision Angular Contact Ball Bearings 10x26x8mm Sealed Spindle Tools
Design Features
The 7000C-2RZ Precision Angular Contact Ball Bearing is crafted from superior materials and manufactured to exacting standards. It's perfectly suited for high-speed spindles and precision instruments where accuracy and rapid operation are essential. This bearing delivers outstanding performance and maintains reliability even under challenging conditions.
Bearing Number Dimensions(mm) Basic Load Rating(N) Limiting Speed(rpm) Weight(Kg)
Inner Diameter Outer Diameter Width Chamfer Dynamic Static Grease Oil
7000C-2RZ 10 26 8 0.6 0.3 6100 4300 19000 / 0.02
Ring Material Steel
Roller Material Steel Ball, Ceramic available
Cage Material Bakelite Phenolic
Contact Angle 15°, 25° & 40° available
Lubrication Required Grease
Matched Arrangement Available
Preload Available
Number Of Bearings In Matched Set 2 pcs/set
Universal Matching Bearing Yes, DB, DF, DT (Back to Back, Face to Face, Tandem)
Temperature Range -30°C ~ +110°C
ABEC Rating Precision P4 (ABEC7) P5, P2 available
CERTIFICATE RoHS, IATF16949:2016
For Load Direction Angular Contact
Service OEM & ODM Customized Services
Samples Please Contact Us
Service Online Support, Professional Service
Size Standard, For custom sizes, please contact us
Factory Manufacturer Yes
7000C-2RZ Precision Angular Contact Ball Bearing 10x26x8mm P4 Precision Sealed 2RZ for Spindle Tools 7000C-2RZ Precision Angular Contact Ball Bearing 10x26x8mm P4 Precision Sealed 2RZ for Spindle Tools
Key Design Features
  • Dimensions: Bore Diameter: 10 mm, Outer Diameter: 26 mm, Width: 8 mm
  • Material Quality: Crafted from high-quality materials to ensure durability and reliability under demanding conditions
  • Precision Manufacturing: Manufactured to extremely tight tolerances, ensuring superior dimensional and geometric accuracy
  • High-Speed Capability: Optimized for high-speed operation with minimal heat generation and friction
  • Load Capacity: Capable of handling both radial and axial loads efficiently
  • Preload Options: Available with various preload options to enhance stiffness and reduce play
  • Surface Finish: Superior surface finish on raceways and rolling elements reduces noise and extends service life
This bearing is an essential component in industries that demand high precision and performance, such as machine tool spindles, high-speed machinery, aerospace components, medical equipment, semiconductor manufacturing, automotive industry, and scientific instruments.
Applications
  • Aerospace: Aircraft Landing Gear, Gyroscopes - Equipment that requires high precision and reliability
  • Machine Tools: Spindles, Feed Systems - Components that demand high precision and stability
  • Industrial Automation: Robot Joints, Servo Motors - Transmission systems requiring high precision and reliability
  • Medical Equipment: High-Speed Dental Tools, Surgical Instruments, Imaging Devices - Applications with stringent requirements for cleanliness and reliability
  • Automotive Components: Generators, Air Conditioning Compressors, Steering Systems - Rotating parts of vehicle auxiliary systems
  • Precision Instruments: Measuring Instruments, Laboratory Equipment - Occasions where precision is strictly required
  • Wind Power Equipment: Generators, Yaw Systems - Components needing high reliability and long service life
  • Semiconductor Manufacturing Equipment: Wafer Handling Equipment - Devices that require high precision and operate in cleanroom environments
