Specifications
Brand Name :
YEAWEY
Model Number :
CQD30BS
Certification :
CE ISO，SGS
Place of Origin :
China
MOQ :
1 unit
Price :
6000-7500 usd
Payment Terms :
L/C, T/T, D/P, D/A, Western Union, MoneyGram
Supply Ability :
100 units per month
Delivery Time :
5-8 working days
Packaging Details :
Plastic bag
Product name :
3T Electric Reach stacker 24V seat type
Load capacity :
3T
Lift height :
3-6m
Mast type :
Triplex mast
Battery :
48V/400Ah
Service weight :
3850 kgs
Description

3000kg 48V CQD30BS 3.0T Electric Reach forklift truck stand type triplex 3-6m mast

Main information:

Curtis AC controller

AC lift and drive motor

Lift height 3m to 6m

Lead acid battery 24V/2810AH

Stand type

The YEAWEY Lead acid / Lithium battery stand reach truck adopts four columns for cabin to penetrate the frame which is both beautiful and safe.Wide field of vision and driving space along with high elastic shock-absorbing seats provide a unique driving pleasure.

Motor current detection control

Prevent the motor from being damaged due to excessive motor current.

Electromagnetic brake and hydraulic brake

combination of electromagnetic braking and hydraulic braking, short braking distance, no deviation, no impact, safe and reliable.

Parking electromagnetic brake

It can realize one-button operation function either on the ramp and smooth ground.

Item Model CQD30BS-30
1 Power type Electric
2 Drive mode Standing Type
3 Load capacity Q(kg) 3000
4 Load center C(mm) 500
5 Wheel base Y(mm) 1770
6 Reach distance L(mm) 610
7 Self weight with battery kg 3850
8 Tire type Pu solid tire
9 Front tire size ∅×w(mm) 280*135
10 Rear tire size ∅×w(mm) 382*142
11 Balance wheel size ∅×w(mm) 180*76
12 Track width, front wheels b10(mm) 1330
13 Height-Mast lowered h1(mm) 2280
14 Free Lift Height h2(mm) 0
15 Lift Height h3(mm) 3000
16 The maximum height of the gantry during homework h4(mm) 3945
17 The height of overhead guards h14(mm) 2305
18 The height when fork lowered h13(mm) 45
19 Tilt-Forward/Back α/β(°) 3/5
20 Overall length without forks/with forks l2(mm) 2150/2640
21 Width of the body b1(mm) 1460
22 Fork Dimensions s/e/l(mm) 45/125/1070
23 Fork Spread b5(mm) 244-820
24 Min ground clearance m2(mm) 80
25 Aisle Width,pallet 1000*1200mm Ast(mm) 3220
26 Min. Turning radius Wa(mm) 2200
27 Max.walking speed km/h 8/7
28 Max. lifting speed m/s 0.240/0.170
29 Max. lowing speed m/s 0.300/0.380
30 Grade Ability ％ ≤8
31 Drive brake electromagnetic
32 Drive motor kw 8
33 Lift motor kw 12
34 Battery type Lead acid
35 Battery capacity V/Ah 48V400Ah
36 Charger V/Ah 48V/50A
37 DriveControllingType alternating current
38 The noise level in the driver's ear according to EN12053 dB(A) 75
